Connecting the Scanner
Figure 1
. RS-232 Serial Connection
Cable Connector
Retainer Boss
Captive
Screws
USB Connection —
Connect the scanner to a USB port on the termi-
nal/PC using the correct USB cable for the interface type you ordered.
Reference
.
Figure 2
Figure 2. USB Connection
or...
or...
or...
Product Reference Guide
1-3
