Argo Genius Operating Instructions Manual page 5

1. Air entry on right
2. LED indicator
3. Right-hand side panel
4. Touch control panel
5. Rear structure
6. Power cord
7. Nut support
8. Air entry on left
9. Decorative panel
10. Left-hand side panel
INSTALLATION INSTRUCTIONS
The appliance must be installed. Observe the following instructions:
1. Extract the parts from the package to assemble them.
2. Attach the shaft to the hole on the base and secure it tightly with the screw (Picture 1).
3. Attach the fan body to the shaft (Picture 2).
4. Secure the fan body and shaft with the screw (Picture 3).
5. Place the fan on a flat surface, switch it on and follow the instructions of the user manual. (Picture 4).
Picture 1
V 12/16
DESCRIPTION OF PARTS
HOW TO USE THE APPLIANCE
Picture 2
11. Front structure
12. Presence sensor
13. Remote control receiver
14. Swinging base
15. Remote control
16. Remote control support
17. Shaft
18. Base
19. Base weight balancing system
Picture 3 Picture 4
