DC DESK AND STAND FAN
IPNO
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance operations.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage.
Keep these instructions in a safe place for future reference.
V 11/19
12
Advertisement
Table of Contents
Related Manuals for Argo IPNO
Summary of Contents for Argo IPNO
- Page 1 DC DESK AND STAND FAN IPNO OPERATING INSTRUCTIONS Read the instructions carefully before operating the appliance or carrying out maintenance operations. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Keep these instructions in a safe place for future reference.
-
Page 2: General Safety Information
GENERAL SAFETY INFORMATION Use this fan only as outlined in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or injury to people. Ensure that the mains power complies with the voltage specified on the fan ’s data plate (220-240V~/50Hz). - Page 3 Do not operate the appliance if it has fallen from a height or has suffered damage in any way. Contact qualified technical personnel to examine the appliance or perform any electrical or mechanical repairs. The most common cause of overheating is the build-up of dust in the appliance.
- Page 4 A fan has inside parts that generate arcs or sparks. It must not be used in areas that could be dangerous, such as areas at risk of fire, explosions loaded with chemicals or atmospheres full of humidity. Do not use the fan in the immediate vicinity of bathtubs, showers, washbasins and swimming pools.
-
Page 5: Description Of Parts
DESCRIPTION OF PARTS 1. Grill cover plate 2. Inner column 3. Outer column 4. Fan base 5. Grill hoop 6. Rear grill 7. Rear motor cover 8. Flexible Rack 9. Height adjustable button V 11/19... - Page 6 ASSEMBLY INSTRUCTIONS Open the box and remove the parts of the appliance. Put the outer column into the base and put the lock nut under the base, rotating it in a clockwise direction and ensure it is fixed Assembly diagram of the parts Motor shaft.
-
Page 7: How To Use The Appliance
Tighten the nut on the motor shaft With the aid of the ring join front and rear grill and tighten the screw on the ring HOW TO USE THE APPLIANCE CONTROL PANEL AND AVAILABLE FUNCTIONS Plug the power cord into an appropriate power outlet (220-240V~/50HZ). Symbol : Mode selection Pressing 1 time: to select Timer: press + and –... -
Page 8: Remote Control
Ventilation Mode: this fan has 3 ventilation modes Normal, Natural and Sleep. Symbol : Mode selection Pressing 1 time: to select Timer: press + and – to set the ventilation time of product Pressing 2 times: the unit starts working in Natural mode: press + and – to select ventilation speed Pressing 3 times: the unit starts working in Sleep mode: press + and –... -
Page 9: Maintenance And Storage
HOW TO INSERT / REMOVE THE REMOTE CONTROL BATTERY (refer to the diagram) Open the battery cover on the back of the remote control (press and pull the cover with the side hook). Place the battery inside the cover, making sure the polarity is correct. Slot the cover back into position on the remote control. - Page 10 Put the grids in water with a liquid detergent for about ten minutes, brush and dry with a dry cloth. Allow the appliance to dry completely before using it. Do not apply corrosive detergents or solvents such as petrol. Do not wash the appliance with water. Do not use oils, chemicals or other objects that could damage the surface during cleaning.
