SECTION 3 –
DRIVING YOUR MOTORHOME
Inner
rear
dual
4. Using the cap tool as a remote handle,
unscrew the valve stem cap (retaining cap in
the end of the tool).
18-Hole Steel Wheel with Push-On Full
Wheel Trim
Stylized Chrome Wheels
3-10
NOTE: If the valve stem cap and valve stem
Cap
Tool
5. To check inner dual tire pressure, use the long
6. When tire pressure testing is complete,
7. Remove cap tool from valve stem cap.
Rear Outer Dual Valve Stem
Access
NOTE: Rear Outer Dual is equipped with a fill-
1. Obtain a double angle push/pull truck tire
2. To check rear outer dual tire pressure, use the
extension unscrew as an assembly, pull
the assembly out of the cap tool end,
remove valve stem cap, insert valve stem
extension into cap tool, and reinstall
valve stem extension onto valve stem
until snug.
Pull off cap tool and re-insert valve stem
cap into end of hose.
handle of the tire gauge to control alignment
and avoid misaligned valve stem deflection.
reinstall the valve stem cap (with the cap still
retained in the cap tool end).
through extension (no valve stem cap).
gauge.
long handle of the tire gauge to control
alignment on the fill-through extension.
