Nortek GFH09(2.6)FMK4DH Owner's Manual

Flex match series floor and ceiling type indoor unit (for north america)

Hide thumbs

page of 19

/ 19
Bookmarks

Quick Links

Download this manual

Nortek Global HVAC, LLC

Please read this owner's manual carefully before operation and retain it for future reference

Specifications & illustrations subject to change without notice or incurring obligations

Flex Match Series

Floor and Ceiling Type Indoor Unit

(For North America)

Owner's Manual

Heat Pump

Models:

Need help?

Do you have a question about the GFH09(2.6)FMK4DH and is the answer not in the manual?

Questions and answers

Summary of Contents for Nortek GFH09(2.6)FMK4DH

Page 1: Heat Pump
Nortek Global HVAC, LLC Flex Match Series Floor and Ceiling Type Indoor Unit (For North America) Owner's Manual Heat Pump Models: Please read this owner’s manual carefully before operation and retain it for future reference Specifications & illustrations subject to change without notice or incurring obligations...
Page 2 User Notice The total capacity of the indoor units connected can not exceed 150% of that of the outdoor units. The entire system (indoor and outdoor units) must have a dedicated power supply that can total power supply switch. operation. clears the unit of conditioned (heated or cooled) air.
Page 3 Contents 1 Safety Precautions ..................1 ................................................................................................................................................6 ............................................. 10 ................. 10 6 Maintenance Method ............................................................................................................................................... 15 ....................
Page 4: Safety Precautions
Flex Match 1 Safety Precautions Warning!: death. Caution! Warning! Air conditioner must use dedicated power supply circuit and switches for short circuit help. malfunction.
Page 5 Flex Match The installation of the air conditioner must be conform to all national and local safety laws. installation manual. Select a location where condensate water can be easily drained out. Select location where connections to outdoor unit and condensate drain are convenient. pool.
Page 6 Flex Match >1500mm (5 ft) >600mm >600mm >1000mm >600mm >600mm >1500mm (5 ft) (1). to ensure effective operation. this manual. location. Ceiling type Floor type (1). described bellow.
Page 7 Flex Match Installation Warning! (5). (6). Caution!
Page 8 Flex Match Cellin Suspension bolt...
Page 9 Flex Match Model Caution: The supply power for all indoor unit must be connected to outdoor unit. Open front panel. and connect the power line and the communication line from the outdoor unit to the POWER INDOOR UNIT B INDOOR UNIT D INDOOR UNIT A INDOOR UNIT C OUTDOOR UNIT...
Page 10 Flex Match Caution!
Page 11 Flex Match (1). Use the included drain hose and clamp (When drain hose is connected) Clamp Not to be lifted Not to be Cramp (Accessory) (Accessory) Air outlet...
Page 12 Flex Match Pipe Flare Nut Pipe Spanner (1). with plastic tape. Notes:...
Page 13 Flex Match Air outlet Guide louver Front panel pipe Air inlet Suitable model Note: Illustation is for reference only. There may be a slight difference in appearance of different sizes. Indoor side state Outdoor side state Wet bulb Wet bulb temp.
Page 14 Flex Match 6 Maintenance Warning! rinse air conditioner with water under any circumstances. conditioner.) Warning! Suggestion: will be overloaded and consume 6% Clean the air conditioner and the remote control with dry cloth or a vacuum cleaner. If damp Caution the unit to be warped.
Page 15 Flex Match The desired temperature should be set at a moderate level to avoid of unnecessary condition the entire room.
Page 16 Flex Match on the nameplate of the unit. Only use fuses with specified capacity installed by professionals. the indoor and outdoor unit to avoid malfunction or poor performance. play with air conditioner. The heat may warp plastic parts.
Page 17 Flex Match Warning! to be malfunctions, but actually are not. Check for the following conditions before calling for service. "Malfunction" Possible Analysis The unit will not restart after Unit emits and odor when first turned on. inside air conditioner. Is the unit turned off? The air conditioner will not run.
Page 18 Flex Match supply and contact service center for help.
