Mounting

One of the important differences between the Surface Mount and the Through-hole modules is the way they
mount to the PCB. Different mounting techniques are required.
Digi International has designed a footprint which will allow either module to be attached to a PCB. The layout is
shown below. All dimensions are in inches.
XBee/XBee-PRO ZigBee RF Modules User Guide
Name
SPI_MISO / DIO15
[reserved]
[reserved]
[reserved]
[reserved]
[reserved]
CTS / DIO7
ON / SLEEP / DIO9
ASSOCIATE / DIO5
RTS / DIO6
AD3 / DIO3
AD2 / DIO2
AD1 / DIO1
AD0 / DIO0
[reserved]
[reserved]
GND
DIO4
VREF
GND
RF
Mounting
TH Pin #
11
12
13
14
15
16
17
18
19
20
