Connections and operating elements
1 Light aperture.
2 Fan.
3 IEC chassis plug for the mains cable with fuse holder.
4 [DMX Out]
DMX output.
5 [DMX In]
DMX input.
6 Infrared sensor for receiving remote control signals.
7 Microphone for sound control.
8 [ENTER]
Calls up the menu for the respective operation mode, confirms a set value.
9 [DOWN]
Decreases the displayed value by one and selects menu items.
24
moving head
