- Page 1 PinSpot LED 3W 6,5K PinSpot user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 16.01.2018, ID: 427154...
-
Page 3: Table Of Contents
Table of contents Table of contents Safety instructions............................. 4 Features................................8 Installation..............................9 Connections and controls........................12 Technical specifications........................14 Cleaning............................... 15 Changing the lens........................... 16 Protecting the environment......................17 PinSpot LED 3W 6,5K... -
Page 4: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used as an electronic illumination effect using LED technics. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con- ditions is considered to be improper and may result in personal injury or property damage. - Page 5 Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged. PinSpot LED 3W 6,5K...
- Page 6 Safety instructions DANGER! Electric shock caused by short-circuit Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a registered electrician. WARNING! Eye damage caused by high light intensity Never look directly into the light source.
- Page 7 Failure to do so could result in damage to the device and possibly injure the user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. PinSpot LED 3W 6,5K...
-
Page 8: Features
Features Features Powerful PinSpot LED spotlight. Special features of the device: 3 watt CREE XPE2 white light LED with 6.500 K Beam angle: 3° or 10° (lenses supplied) Adjustable mounting bracket Compact and lightweight design PinSpot... -
Page 9: Installation
Risk of injury caused by falling objects Make sure that the installation complies with the standards and rules that apply in your country. Always secure the device with a secondary safety attachment, such as a safety cable or a safety chain. PinSpot LED 3W 6,5K... - Page 10 Installation NOTICE! Risk of overheating Always ensure sufficient ventilation. The ambient temperature must always be below 40 °C (104 °F). NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand.
- Page 11 Installation The safety cable must be threaded through the safety cable eyelet on the rear side. PinSpot LED 3W 6,5K...
-
Page 12: Connections And Controls
Connections and controls Connections and controls PinSpot... - Page 13 Connections and controls 1 Mounting bracket 2 Locking screw for the mounting bracket. 3 Retaining ring for the lens 4 Lens PinSpot LED 3W 6,5K...
-
Page 14: Technical Specifications
Technical specifications Technical specifications Illuminant 3 W CREE XPE2 white light LED with 6.500 K Beam angle 3° or 10° Operating supply voltage 100 – 240 V 50/60 Hz Power consumption 3.5 W Dimensions (L × H × D) 160 mm × 105 mm × 67 mm Weight 0.6 kg PinSpot... -
Page 15: Cleaning
The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device. Clean with a soft cloth using our lamp and lens cleaner (item no. 280122). Always dry the parts carefully. PinSpot LED 3W 6,5K... -
Page 16: Changing The Lens
Changing the lens Changing the lens The spot light comes with a 3° and a 10° lens. This is how to change the lens: Turn the retaining ring of the lens counterclockwise and remove it. Remove the lens carefully. Insert the other lens carefully. Reinstall the retaining ring and turn it clockwise. -
Page 17: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. PinSpot LED 3W 6,5K... - Page 18 Notes PinSpot...
- Page 20 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
