Preface
IST5
10 – 40 KVA
Preface
Usage
The manual contains information on installing, using, operation and maintenance of
the Tower UPS. Please carefully read this manual prior to installation.
Users
Technical Support Engineer
Maintenance Engineer
Note
Our company is providing a full range of technical support and services. Customer
can contact our local office or customer service center for help.
The manual will update irregularly, due to the product upgrading or other reasons.
Unless otherwise agreed，the manual is only used as guide for users and any
statements or information contained in this manual make no warranty expressed or
implied.
Tower UPS 10kVA~40kVA User Manual
I
Advertisement
Table of Contents
Related Manuals for AEC IST5015
Summary of Contents for AEC IST5015
- Page 1 Preface IST5 10 – 40 KVA Preface Usage The manual contains information on installing, using, operation and maintenance of the Tower UPS. Please carefully read this manual prior to installation. Users Technical Support Engineer Maintenance Engineer Note Our company is providing a full range of technical support and services. Customer can contact our local office or customer service center for help.
- Page 2 Contents Contents 1. Safety Precautions ......................... 1 Safety Message Definition ......................1 Warning Label ........................... 1 Safety Instruction ........................1 Move & Install .......................... 1 Debug & Operate ........................2 Maintenance & Replacement ....................2 Battery Safety ..........................3 Disposal ............................. 4 2.
- Page 3 Contents 3.7.2 Communication Interface ..................29 4. LCD Panel ........................... 30 4.1 Introduction ........................30 4.2 LCD panel for Cabinet ...................... 30 4.2.1 LED Indicator ......................30 4.2.2 Control and Operation Keys ................... 31 4.2.3 LCD Screen ......................32 4.3 System Information Window .................... 34 4.4 Menu Window ........................
-
Page 5: Safety Precautions
Safety Precautions 1. Safety Precautions This manual contains information concerning the installation and operation of Tower UPS. Please carefully read this manual prior to installation. The Tower UPS cannot be put into operation until it is commissioned by engineers approved by the manufacturer (or its agent). Not doing so could result in personnel safety risk, equipment malfunction and invalidation of warranty. -
Page 6: Debug & Operate
Safety Precautions result in electric shock. Do not start the system if any damage or abnormal parts founded. Contacting the UPS with wet material or hands may be subject to electric shock. Warning Use proper facilities to handle and install the UPS. Shielding shoes, protective clothes and other protective facilities are necessary to avoid injury. - Page 7 Safety Precautions These precautions should be followed implicitly at all times. Particular attention should be paid to the recommendations concerning local environmental conditions and the provision of protective clothing, first aid and fire-fighting facilities. Ambient temperature is a major factor in determining the battery capacity and life.
-
Page 8: Product Introduction
Installation Instruction 2. Product Introduction 2.1 System Configuration The Tower UPS is configured by the following part: Rectifier, Charger, Inverter, Static Switch and Manual Bypass Switch. One or several battery strings should be installed to provide backup energy once the utility fails. The UPS structure is shown in Fig. 2-1. Manual Bypass Static Switch Bypass Input... -
Page 9: Battery Mode
Installation Instruction Manual Bypass Static Switch Bypass Input Main Input Rectifier/ Inverter Discharger Load Output Switch Battery Charger Fig 2-2 Normal mode operation diagram 2.3.2 Battery Mode Upon failure of the AC mains input power, the inverter of power modules, which obtain power from the battery, supply the critical AC load. -
Page 10: Maintenance Mode (Manual Bypass)
Installation Instruction Manual Bypass Static Switch Bypass Input Load Main Input Rectifier/ Inverter Discharger Output Switch Battery Charger Fig. 2-4 Bypass mode operation diagram 2.3.4 Maintenance Mode (Manual Bypass) A manual bypass switch is available to ensure continuity of supply to the critical load when the UPS becomes unavailable e.g. -
Page 11: Auto-Restart Mode
Installation Instruction Manual Bypass Static Switch Bypass Input Main Input Rectifier/ Inverter Discharger Load Output Switch Battery Charger Fig.2-6 ECO Mode operation diagram Note There is a short interruption time (less than 10ms) when transfer from ECO mode to battery mode, it must be sure that the interruption has no effect on loads. -
Page 12: Installation Instruction
Installation Instruction RS232 SNMP Battery Cold Start RS485 Maintenance CB Bypass Input CB Parallel Board Main input CB Output CB Contact Protective Connection terminal Cover Fig. 2-11 10/15 kVA back appearance SNMP Dry Contact Cold start button Parallel board Bypass Input CB Main input CB Air vent Maintenance... - Page 13 Installation Instruction Parallel board Cold start Dry contact Output CB Bypass Input CB Air vent Maintenance Input CB switch Connection terminals Fig. 2-13 40kVA back appearance Note The Standard product is configured with single input; the dual-input option is available, with an additional breaker for the main input.
-
Page 14: Location
Installation Instruction 3. Installation Instruction 3.1 Location As each site has its requirements, the installation instructions in this section are to act as a guide for the general procedures and practices that should be observed by the installing engineer. 3.1.1 Installation Environment The UPS is intended for indoor installation and uses forced convection cooling by internal fans. -
Page 15: Unloading And Unpacking
Installation Instruction The weight for the UPS cabinet is shown in Table 1.1 Table 1.1Weight for the cabinet Configuration Weight 10kVA/15kVA Standard Backup Type 50kg(No Batteries Included） 10kVA/15kVA Long Backup Type 28kg 20kVA/30kVA Standard Backup Type 88kg(No Batteries Included) 20kVA/30kVA Long Backup Type 50kg 40kVA Long Backup Type 61kg... - Page 16 Installation Instruction Fig.3-6 Disassemble the case 4. Remove the protective foam around the cabinet. Fig.3-7 Remove the protective foam IST5 Tower UPS 10kVA~40kVA User Manual...
-
Page 17: Positioning
Installation Instruction 5. Check the UPS. (a) Visually examine if there are any damages to UPS during transportation. If any, contact to the carrier. (b) Check the UPS with the list of the goods. If any items are not included in the list, contact to our company or the local office. -
Page 18: Battery
Installation Instruction Fig.3-8 Supporting structure（Bottom view） The steps to position the cabinet are as follows： 1. Ensure the supporting structure is in good condition and the mounting floor is smooth and strong. 2. Retract the anchor bolts by turning them counterclockwise using wrench, the cabinet is then supported by the four wheels. -
Page 19: Cable Entry
Installation Instruction 3.5 Cable Entry Cables can enter the UPS cabinet from the side or from the bottom. Cable entry is made possible through a blanking plate fitted at the bottom of the equipment. The cable entry is shown in Fig.3-11. Cable connection C a b l e c o n n e c t i o n Fig.3-10 Cable entry... -
Page 20: Power Cables
Installation Instruction 20/30A 40/60A Battery Input current(A) Battery Input Cable Section （mm²） Cable Section （mm²） Note The recommended cable section for power cables are only for situations described below： Ambient temperature：30℃. AC loss less than 3%，DC loss less than 1%，The length of the AC power cables are no longer than 50 m and the length of the DC power cables are no longer than 30 m. -
Page 21: Connecting Power Cables
Installation Instruction 3.6.4 Connecting Power Cables The steps of connecting power cables are as follows: 1. Verify that all the switches of the UPS are completely open and the UPS internal maintenance bypass switch is open. Attach necessary warning signs to these switches to prevent unauthorized operation. -
Page 22: Control And Communication Cables
Installation Instruction Attention The operations described in this section must be performed by authorized electricians or qualified technical personnel. If you have any difficulties, contact the manufacturer or agency. Warning Tighten the connections terminals to enough torque moment, refer to Table 3.3, and please ensure correct phase rotation. -
Page 23: Dry Contact Interface
Installation Instruction J4-2 +24V_DRY +24V J4-3 +24V_DRY +24V J4-4 REMOTE_EPO_NO Trigger EPO when shorted with J4-3 J5-1 +24V_DRY +24V Input dry contact , function is settable , J5-2 GEN_CONNECTED Default: interface for generator J5-3 GND_DRY Ground for +24V Output dry contact, function is settable. J6-1 BCB Drive Default: Battery trip signal... - Page 24 Installation Instruction The input dry contact J2 and J3 can detect the temperature of batteries and environment respectively, which can be used in environment monitoring and battery temperature compensation. Interfaces diagram for J2 and J3 are shown in Fig.3-14, the description of interface is in Table 3.6.
- Page 25 Installation Instruction Port Name Function J4-1 REMOTE_EPO_NC Trigger EPO when disconnect with J4-2 J4-2 +24V_DRY +24V +24V_DRY +24V J4-3 REMOTE_EPO_NO Trigger EPO when connect with J4-3 J4-4 Generator Input Dry Contact The default function of J5 is the interface for generator J5 Connect pin 2 of J5 with +24V power supply;...
- Page 26 Installation Instruction Port Name Function BCB contact drive, provides +24V voltage ， 20mA J6-1 BCB_DRIV drive signal BCB contact status, connect with the normally open J6-2 BCB_Status signal of BCB J7-1 GND_DRY Power ground for +24V BCB on-line input (normally open) , BCB is on-line J7-2 BCB_Online when the signal is connecting with J7-1...
- Page 27 Installation Instruction Fig.3-19 Integrated warning dry contact interface diagram Table3.11 General alarm dry contact interface description Port Name Function Integrated warning relay (normally closed) will be J9-1 GENERAL_ALARM_NC open during warning Integrated warning relay (normally open) will be J9-2 GENERAL_ALARM_NO closed during warning J9-3 GENERAL_ALARM_GND Common terminal...
-
Page 28: Communication Interface
Installation Instruction Port Name Function J10-3 UTILITY_FAIL_GND Common terminal 3.7.2 Communication Interface RS232、RS485 and USB port：Provide serial data which can be used for commissioning and maintenance by authorized engineers or can be used for networking or integrated monitoring system in the service room. SNMP: Used on site installation for communication (Optional). -
Page 29: Lcd Panel
Operations 4. LCD Panel 4.1 Introduction This chapter introduces the functions and operator instructions of the operator control and display panel in detail, and provides LCD display information, including LCD display types, detailed menu information, prompt window information and UPS alarm information. -
Page 30: Control And Operation Keys
Operations Indicators State Description Steady green Load supplied by bypass Bypass abnormal or out of normal range, or static bypass switch Steady red Bypass fault indicator Flashing red Bypass voltage abnormal Bypass normal Steady green Load supplied by inverter Flashing Inverter on, start, synchronization or standby (ECO mode) for at green least one module... -
Page 31: Lcd Screen
Operations 4.2.3 LCD Screen After the monitoring system starts self-test, the system enters the home page, following the welcome window. The home page is shown in Fig.4-2. Home page consists of System Information Window, Menu Window and Current Command and Record Menu. Fig.4-2 Home page The description of LCD icons is shown in Table 4.4. - Page 32 Operations HOME I/P MAIN NEXT 220.1 V 220.1 V 220.1 V 45.0 A 45.0 A 45.0 A 50.01 Hz 50.01 Hz 50.01 Hz 0.99 PF 0.99 PF 0.99 PF Fig.4-3 Main input page Select the icon of , it will display the information of battery, as shown in Fig.4-4. HOME BATTERY P.1 NEXT...
-
Page 33: System Information Window
Operations System Information Window System Information Window displays the current time and UPS model, as is shown in the following Table 4.5. Table 4.5 Description of System Information Window Content Description UPS mode:3-phase in 3-phase out 20kVA,standard 3320S backup type 16:30 Current time 4.4 Menu Window... -
Page 34: Event List
Operations Menu name Menu item Meaning alarm History log Display all history logs. Display calibration Adjust the accuracy of LCD display MONTH-DATE-YEAR and YEAR-MONTH-DATE Date format set formats can be selected Date & Time Date/Time set Function Settings Language set User can set the language Communication set Control password 1... - Page 35 Operations Maintenance CB Closed- Maintenance CB is Closed Maintenance CB Open-Set Maintenance CB is Open EPO-Set Emergency Power Off Valid Inverter capacity is less then the load Module On Less-Set capacity Module On Less-Clear Incident above disappears Generator Input-Set Generator as the Ac Input Source Generator Input-Clear Incident above disappears Utility Abnormal-Set...
- Page 36 Operations Incident above disappears Rectifier Fail-Clear N# Power Module Inverter Fail Inverter Fail-Set Incident above disappears Inverter Fail-Clear N# Power Module Rectifier Over Temperature Rectifier Over Temp.-Set Rectifier Over Temp.- Incident above disappears Clear N# Power Module Fan Fail Fan Fail-Set Incident above disappears Fan Fail-Clear N# Power Module Output Over Load...
- Page 37 Operations Power Share Fail-Set Power share is not in balance Power Share Fail-Clear Incident above disappears Input Volt Detect Fail-Set Input Voltage is abnormal Input Volt Detect Fail- Incident above disappears Clear Battery Volt Detect Fail- Battery Voltage is abnormal Batt Volt Detect Fail-Clear Incident above disappears Output Volt Fail-Set Output Voltage is abnormal...
-
Page 38: Operations
Operations 5. Operations 5.1 UPS Start-up 5.1.1 Start from Normal Mode The UPS must be started up by commissioning engineer after the completeness of installation. The steps below must be followed： Ensure all the circuit breakers are open. Close the output circuit breaker (CB) and then the input CB and the system starts initializing. -
Page 39: Start From Battery
Operations Note When the system starts, the stored setting will be loaded. Users can browse all incidents during the process of the starting up by checking the menu 5.1.2 Start from Battery The start for battery model is referring to battery cold start. The steps for the start-up are as follows：... -
Page 40: Switching The Ups Into Normal Mode From Bypass Mode
Operations 5.2.3 Switching the UPS into Normal Mode from Bypass Mode Manual ESC Follow the path by selecting the icon of and then s , the system transfer to Normal Mode Note Normally, the system will transfer to the Normal mode automatically. This function is used when the frequency of the bypass is over track and when the system needs to transfer to Normal mode by manual. -
Page 41: Switching The Ups Into Normal Mode From Maintenance Bypass Mode
Operations 5.2.5 Switching the UPS into Normal Mode from Maintenance Bypass Mode These following procedures can transfer the load from the Maintenance Bypass mode to inverter output. After finish of maintenance, close the bypass breaker and the bypass static switch ... -
Page 42: Installation Of Parallel Operation System
Operations turn off the rectifier, inverter and stop powering the load immediately (including the inverter and bypass output), and the battery stops charging or discharging. If the input utility is present, the UPS control circuit will remain active; however, the output will be turned off. - Page 43 Operations Power Supply UPS1 UPS2 UPS3 UPS4 Output Power Supply Load Connected Fig. 5-6 Parallel diagram The parallel board is located at the back of the UPS cabinet, as is shown in Fig.5-7. IST5 Tower UPS 10kVA~40kVA User Manual...
- Page 44 Operations Fig.5-7 Location of the Parallel board All the parallel cables are designed to be shielded and double insulated, and are connected between the UPS to form a loop as shown below in Fig.5-8. Fig.5-8 Parallel connection IST5 Tower UPS 10kVA~40kVA User Manual...
-
Page 45: Parallel System Setting
Operations 5.5.2 Parallel system setting Parallel system connection For field installation, please connect the cables according to Fig.5-6 and Fig.5-8. In order to assure that all units are equally utilized and to comply with relevant wiring rules, the following requirements apply: 1. - Page 46 Operations Fig.5-11 Connectors on Parallel board (PS1409_TF1) 并 机 跳 针 Zoom i n j u mper connnect o rs Fig.5-12 Connectors on Control board (PS1203_CT1) IST5 Tower UPS 10kVA~40kVA User Manual...
- Page 47 Operations 1. Parallel boards settings A. For single UPS, no need parallel board. When a parallel board is installed, connectors of J33 to J42 should be shorted by the jumpers. B. For 2 UPS in parallel, short the connectors of J33/J35/J37/J39/J41 by jumpers on each board, keep connectors of J34/J36/J38/J39/J42 open C.
-
Page 48: Maintenance
Product Specification 6. Maintenance This chapter introduces UPS maintenance, including the maintenance instructions of power module and monitoring bypass module and the replacement method of dust filter. 6.1 Precautions 1. Only certified engineers are authorized to maintain the UPS. 2. The components or PCBs should be disassembled from top to bottom, so as to prevent any inclination from high gravity centre of the cabinet. -
Page 49: Installation Of Internal Battery
Safety Precautions Daily inspection is very important! Check and confirm the battery connection is tightened regularly, and make sure there is no abnormal heat generated from the battery. Warning If a battery has leakage or is damaged, it must be replaced, stored in a container resistant to sulfuric acid and disposed of in accordance with local regulations. - Page 50 Product Specification 3．Connect the battery cable according to the series number 4．Recover the cover Installation of battery Fig.6-1 Fig.6-2-1 Cable interconnection of the battery string IST5 Tower UPS 10kVA~40kVA User Manual...
- Page 51 Safety Precautions There are 8 groups of batteries in series, with 5 cells for each group. The interconnection among groups is via cable with Anderson Socket. Layer 1. The positive of the battery 1# is connected to battery breaker CB4-2, via the cable labeled L1, and the negative of battery 40# is connected to CB4-6, via the cable labeled L2, as shown in Fig.6-2.
- Page 52 Product Specification Layer 3. The positive of the battery 11# is connected to the negative of battery 10#, via the cable labeled L4, and the negative of battery 30# is connected to the positive of battery 31#, via the cable labeled L4, as shown in Fig.6-4. Fig.6-2-4 Cable connection of Lay 3 Layer 4.
- Page 53 Safety Precautions Fig.6-2-5 Cable connection of Lay 4 Warning Make sure the polarity of the battery is correct according to the diagrams above. Test and confirm the battery voltage before connectting to the main circuit. IST5 Tower UPS 10kVA~40kVA User Manual...
-
Page 54: Product Specification
Product Specification 7. Product Specification This chapter provides the specifications of the product, including environmental characteristics mechanical characteristics and electrical characteristics. 7.1 Applicable Standards The UPS has been designed to conform to the following European and international standards: Table 7.1 Compliance with European and International Standards Item... -
Page 55: Electrical Characteristics
Safety Precautions 7.3 Mechanical Characteristic Table 7.3 Mechanical Characteristics for Cabinet Unit Model 10kL/15kL 10kS/15kS 20S/30S 20L/30L 40kVA Dimension 250*660*530 250*840*715 350*738*1335 250*680*770 250*836*770 W×D×H Weight Color BLACK,RAL 7021 Protection Level IP20 IEC（60529） 7.4 Electrical Characteristics 7.4.1 Electrical Characteristics (Input Rectifier) Table 7.5 Rectifier AC input Mains ）... -
Page 56: Electrical Characteristics (Intermediate Dc Link)
Product Specification 7.4.2 Electrical Characteristics (Intermediate DC Link) Table 7.6 Battery Items Unit Parameters Battery bus voltage Rated ： ±240V Quantity of lead- Nominal 40=[1 battery(12V)] ,240=[1 battery(2V)] acid cells V/cell （ 2.25V/cell(selectable from 2.2V/cell ～ 2.35V/cell) Float charge voltage VRLA ）... -
Page 57: Electrical Characteristics (Bypass Mains Input)
Safety Precautions 7.4.4 Electrical Characteristics (Bypass Mains Input) Table 7.8 Bypass Mains Input Item Unit Value Rated AC 380/400/415 (three-phase four-wire and sharing neutral with the bypass) voltage 125% Long term operation; 125%~130% for 10min; ％ Overload 130%~150% for 1min; 150%~400% for 1s;...
