Trycom Technology TRP-C28 User Manual page 36

Command ID 0F SS NN 00 CN BC 00 (CRC)
ID
Syntax
0F
Description
SS
NN
00 CN
BC
00
Response ID 0F SS NN 00 00 (CRC)
ID 8F ER (CRC)
Example:
Send command :" 01 0F 02 00 00 04 01 00 ".....Clear channel 0~3 counter value.
Response:" 01 0F 02 00 00 0F " Command valid.
Send command :" 01 0F 03 00 00 04 01 00 ".....Save all channel counter to EEPROM
Response:" 01 0F 02 00 00 0F " Command valid.
Send command :" 01 0F 00 00 00 04 01 03 ".....Set the relay output
Response:" 01 0F 00 00 00 04 " Command valid.
11. How to use the utility for windows
The TRPCOM utility can help you to test and configuration the module's data transmit and
receive digital input and output communication status. User may download TRPCOM software
Address of setting module 1~247
Function Code
SS=00 Digital Output
SS=02 Clear Counter value
SS=03 Save Counter value to EEPROM
Start channel number NN=00~03
Channel number 1~4
Byte Counter=01
Output value
Command Valid
ID 85 :Function Code
ER=00 Syntax error
ER=01 Data Format error
ER=02 Start channel error
ER=03 I/O out of range
36
