- Page 1 INSTALLATION AND INSTRUCTION MANUAL Star Mini Phantom ™ 35-Pattern Undercover Interior Mini LED Light Models ULB9 and ULB9-1 (Discrete LEDs) Models ULB9S and ULB9S-1 (Starburst LEDs) PLITSTR46 REV. H 1/26/12...
- Page 2 IMPORTANT: Please read all of the following instructions before installing your new light. CAUTION: Please be sure to check that your cigarette plug outlet or hard wire is properly fused with a 5 amp fuse. Testing the light before this fuse is properly installed will void the warranty on the light.
- Page 3 General Mini Phantom Typical mounting locations for the ™ include the front windshield of a vehicle, in the rear window, on the rear deck, or directed out the side window. While there is no specific “top” or “bottom” to the light, nor a specific “right” or “left” side, you still must take into account which mount you will be using and which way the main bracket should be mounted to the rear of the light, based on where you are going to mount the light and where you will run the cord.
- Page 4 Mounting Mini Phantom 1. The ™ can be mounted in the front windshield of a vehicle, in the rear window, on the rear deck, or directed out the side window. All of the mounts will require you to attach the mounting bracket to the light.
- Page 5 5. If you are utilizing the suction cup mount, attach the DL15- CUP suction cups to the mounting bracket. Then mount the light in the desired location and skip to step 10. CAUTION: Take extreme caution not to over tighten the suction cups!!! Over tightening of the screws can strip the holes or puncture the inside of the cup and result...
- Page 6 ULB9 and ULB9S Connections and Operation ULB9/9S (cig plug version only) The ULB9 (cig plug version) can be left plugged into the cig plug outlet in your vehicle. It can be turned on and off using the lighted power switch on the cord. The pattern select switch is used to preset the desired pattern.
- Page 7 ULB9-1 and ULB9S-1 Wiring and Operation The ULB9-1 (hard wire) should be wired through a 5 amp fuse (not supplied) and a 12VDC switch (not supplied) capable of handling at least 5 amps. Connect the wires as follows: Black - Good Chassis Ground Red - Power (+12 VDC) White - Synchro: Connect the white wires from the two lights together to synchronize them together.
- Page 8 The heads in these kits use state-of-the-art Light Emitting Diode (LED) technology. These warning lights are comprised of ultra-high intensity LEDs that are controlled by a solid state flasher unit to efficiently produce light output with lifetimes up to 100,000 hours. Under normal circumstances, you will not need to replace any LEDs in this light.
