CYCLONE
CYCLONE
CYCLONE
CYCLONE
SPEAKER MOUNTING KIT
SPBRK-39
DUAL D-44 BRACKET FOR 2020 DODGE RAM
Please Note: These instructions are provided as a general guideline only.
Specific mounting, wiring, and/or weather-sealing may be necessary and are
the sole responsibility of the installer.
responsibility for the integrity of the installation for this or any of its products.
WARNING: ALWAYS WEAR HEARING PROTECTION PER OSHA 1910.95
The manufacturer assumes no
PLIT427-39 REV. -
10/6/20
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Star Headlight & Lantern CYCLONE SPBRK-39
Summary of Contents for Star Headlight & Lantern CYCLONE SPBRK-39
- Page 1 CYCLONE CYCLONE CYCLONE CYCLONE SPEAKER MOUNTING KIT SPBRK-39 DUAL D-44 BRACKET FOR 2020 DODGE RAM Please Note: These instructions are provided as a general guideline only. Specific mounting, wiring, and/or weather-sealing may be necessary and are the sole responsibility of the installer. The manufacturer assumes no responsibility for the integrity of the installation for this or any of its products.
- Page 2 !!! WARNING !!! Devices should be mounted only in locations listed in SAE standard J1849. Assure clearances before drilling in vehicle. Sound levels produced by speakers can cause permanent hearing loss. Never operate this unit without adequate hearing protection for you and others in the area.
- Page 3 2. Access the front bumper extrusion by removing the front fascia/grill/bumper cover assembly per manufacturer instructions. 3. Install speaker and bracket assembly to bumper system: Refer to the diagram on the previous page showing the hardware configuration. Route a 6MM x 1.00 mounting screw and washer (user-supplied) through the speaker bracket (speakers facing towards the front of the vehicle) and then through the front of the bumper.
- Page 4 ONE YEAR LIMITED WARRANTY The manufacturer warrants each new product against factory defects in material and workmanship for one year after the date of purchase. The owner will be responsible for returning to the Service Center any defective item(s) with the transportation costs prepaid. manufacturer will, without charge, repair or replace at its option, products, or part(s), which its inspection determines to be defective.
