Star Mini Phantom
Interior Undercover Mini LED Light
IMPORTANT:
Please read all of the following instructions before installing your new light.
CAUTION: Please be sure to check that your cigarette plug outlet or hard wire is properly
fused with a 5 amp fuse. Testing the light before this fuse is properly
installed will void the warranty on the light.
This light is designed to be mounted on the inside of your vehicle.
It is not intended for exterior applications and is not warranted
against water damage.
It is the sole responsibility of the owner to ensure the warning light is
secure. Check your light every time you enter the vehicle to ensure that
it is mounted securely. The manufacturer assumes no responsibility for
the secure mounting of this light.
PATENTS D530,029 and D632,421
ULB9 Series
(Discrete LEDs)
ULB9S Series
(Starburst LEDs)
™
PLITSTR46 REV. L
6/20/16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Star Headlight & Lantern Star Mini Phantom ULB9 Series
Summary of Contents for Star Headlight & Lantern Star Mini Phantom ULB9 Series
- Page 1 Star Mini Phantom ™ Interior Undercover Mini LED Light PATENTS D530,029 and D632,421 ULB9 Series (Discrete LEDs) ULB9S Series (Starburst LEDs) IMPORTANT: Please read all of the following instructions before installing your new light. CAUTION: Please be sure to check that your cigarette plug outlet or hard wire is properly fused with a 5 amp fuse.
- Page 2 Parts ULB9-**: Standard Mini Phantom Head with Cig Plug 274-ULB9BKT Mounting Kit ULB9S-**: Starburst Mini Phantom Head with Cig Plug ULB9-HOOD-1 Flashback Hood with Windshield Brackets S111-6 Hood Gasket PLABULB9 Reflective Hood Label P30019-267 Pivoting Flush Mount Brackets ULB9-1-**: Standard Mini Phantom Head with Hardwire 274-ULB9BKT Mounting Kit ULB9S-1-**: Starburst Mini Phantom Head with Hardwire...
- Page 3 ULB9S Mounting Front Windshield Adhesive Mount The hood can be installed such that the cord can exit either side. Route the cord through the appropriate slot and slide the hood onto the back of the light until the hooks on the hood “latch”...
- Page 4 (ULB9S Mounting CONT’D) Optional Reflective Hood Label Installation Practice installing label BEFORE removing backing. 1. Align the notch in the label with the center of the hood taking care that the front edge of the label lines up with the front edge of the hood. 2.
- Page 5 (Bracket Mounting CONT’D) ULB9 Bracket Mounting (Deck, Mirror, or Suction Cup) 1. Decide which side you want the cord to exit the light and determine which way you will need to mount the ULB9-BKT to your light. 2. Attach Part A of the mounting bracket, facing the direction you have selected, to the light by using two of the Philips head screws.
- Page 6 ULB9 and ULB9S Connections and Operation ULB9/9S (cig plug version only) The ULB9 (cig plug version) can be left plugged into the cig plug outlet in your vehicle. It can be turned on and off using the lighted power switch on the cord. The pattern select switch is used to preset the desired pattern.
- Page 7 ULB9-1 and ULB9S-1 Wiring and Operation (hardwired version only) The ULB9-1 (hard wire) should be wired through a 5 amp fuse (not supplied) and a 12VDC switch (not supplied) capable of handling at least 5 amps. Connect the wires as follows: Black - Good Chassis Ground Red - Power (+12 VDC) White - Synchro: AFTER PROGRAMMING, Connect the white wires from the two lights...
- Page 8 LED FIVE YEAR LIMITED WARRANTY The manufacturer warrants this LED light against factory defects in material and workmanship for five years after the date of purchase. The owner will be responsible for returning to the Service Center any defective item(s) with the transportation costs prepaid. The manufacturer will, without charge, repair or replace at its option, products, or part(s), which its inspection determines to be defective.
