10. Identify the Left Pedal (40), which is marked with a
sticker. Using an adjustable wrench, firmly tighten
the Left Pedal counterclockwise into the Left Crank
Arm (15). Tighten the Right Pedal (not shown)
clockwise into the Right Crank Arm. Important:
Tighten both Pedals as firmly as possible. After
using the exercise cycle for one week, retighten
the Pedals. For best performance, keep the
Pedals tightened.
Press the tab on the side of the Left Pedal (40) and
adjust the strap to the desired position. Adjust the
other strap in the same way.
11. Make sure that all parts are properly tightened before you use the exercise cycle. Note: Some hard-
ware may be left over after assembly is completed. Place a mat under the exercise cycle to protect the
floor or carpet.
10
Tab
40
Strap
9
15
