Contents
Precautions.................................................................................................... 2
Preface .......................................................................................................... 2
Warranty ........................................................................................................ 2
List of Accessories ......................................................................................... 3
Preparations Before Use ............................................................................... 7
Photo Modes ................................................................................................11
Settings........................................................................................................ 13
Specifications .............................................................................................. 17
Notice .......................................................................................................... 18
S41B
AEE
User manual
1
aee.com
EN
DE
ES
PT
IT
EL
FR
NL
PL
CS
DA
HU
SV
FI
NO
RU
Advertisement
Table of Contents
Related Manuals for AEE S41B
Summary of Contents for AEE S41B
- Page 1 S41B User manual aee.com Contents Precautions....................2 Preface ......................2 Warranty ......................2 List of Accessories ..................3 Preparations Before Use ................7 Photo Modes ....................11 Settings......................13 Specifications ....................17 Notice ......................18...
-
Page 2: List Of Accessories
List of Accessories aee.com Camera TFT display Water-proof housing Plug bracket unit Flat Adhesive Mount USB data cable Quick start guide CD-ROM Moisture-proof foam The accessories you've received may be slightly different from above. The package is subject to change without further notice. - Page 3 Component Guideline aee.com ( L1 ) ( L2 ) ( L3 ) ( L4 ) 14 15 1. Charging status indicator 14. Recording status indicator 2. Recording status indicator 15. Charging status indicator 3. Video recording/Power key 16. Speaker 4. Microphone 17.
- Page 4 2. Description of Indicators Position Green indicator Red indicator Blue indicator L1/L3 L2/L4 Status Flash once and then Startup Flash once Stay on Video Flash slowly recording Audio Flash slowly recording Photo Flash once Stay on shooting Card full...
- Page 5 3. LCD Segment Display 1080P- 25 00:00:01 100-0088 2H30 1888 Video mode Capture mode Icon Functions Working mode (Video recording) Working mode (Photo shooting) 1080P-25 Video resolution Photo resolution 00:00:01 Recording timer 100-0088 Number of recorded files 2H30 Remaining recordable time...
-
Page 6: Preparations Before Use
Preparations Before Use aee.com 1. Charging Start up the unit to check the battery power. If the battery level is low, charge it. Use USB cable to charge video camera: Power adapter Input: 100~240V 0.5A Output: DC 5V 2000mA 2. Insert and Remove The Memory Card Though all TF cards above Class 10 can be used on video camera, high-speed card is recommended to perform high-definition shooting. - Page 7 Video Modes aee.com 1. Basic Operations of Video Recording a. Turn on video camera to enter recording standby mode; b. Aim the lens to the subject and preview it in TFT display; c. Press "Video recording" key once to start video recording;...
- Page 8 3. Parameter Setting For Video Recording Perform the following steps to set the parameters for video recording: a. Press "M" key to enter the setting menu; b. Press "+" / "-" key to select " "; c. Press "<" / ">" key to move cursor to the sub-menu you want to configure, Press "OK" key to enter the sub-menu;...
- Page 9 • View Angle Optional view angle: Wide, Medium, Narrow, Small. : Wide : Medium : Narrow : Small • Bitrate This unit provides two bit rate options: high " " and normal " ". (If high bit rate is selected, you will get clearer picture with increased file size).
-
Page 10: Photo Modes
Photo Modes aee.com 1. Basic Operations of Photo Shooting a. Turn on video camera to enter recording standby mode; b. Cast the lens to the subject and preview it on the display; c. Press the "Shutter" key once to switch the working mode to "photo modes";... - Page 11 • Display Time You can choose to display or not display the photo shooting time at the bottom right corner of the photo.
-
Page 12: Settings
Settings aee.com To set parameters, perform the following operations a. Press "M" key to enter the camera setting menu; b. Press "-" / "+" key to select " "; c. Press "<" / ">" key to move blue cursor to the sub-menu you want to configure, Press "OK"... - Page 13 Playback aee.com 1. Operating Procedure for Playback a. Press the "playback" key to enter playback interface; b. Press "Video recording" key to select the file type and press "OK" key to confirm; : View video files : View photo files : View all video/audio/photo files c.
- Page 14 When playing audio files, the functions of various keys are listed as below: Functions Functions Decrease volume; Increase volume; Press it to return to the file preview Play/pause. interface; 2. Delete Files a. Under file playback or thumbnail preview mode, move the cursor to the file icon you want to delete;...
- Page 15 Accessory Application aee.com Water-proof Housing and Moisture-proof Foam In order to avoid and reduce the dewing on the glass of the water-proof house, we suggest inputting the moistureproof cotton inside the water-proof case in big temperature range environment. Follow these steps to load video camera into water-proof housing:...
-
Page 16: Specifications
Specifications aee.com Description Specifications Visual angle 130° Aperture f/2.4 Digital zoom ratio Pixel 8 million Video recording format Audio recording format Photo format JPG (JPEG) WiFi-Distance/Mobil Device 100 Meter (Max.) Storage medium Up to 64GB external TF card Standard battery capacity... -
Page 17: Notice
Tips aee.com 1. When the unit is in used for long period, it is natural that its surface temperature will rise. 2. If you will not use the unit for long period, it is suggested that you charge it once every 6th month to maintain the performance of battery. - Page 18 FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
