- Page 1 PBCC85 CUTTING TOOL USER MANUAL Safety, Operation and Maintenance © 2017 STANLEY Black & Decker, Inc. New Britain, CT 06053 U.S.A. 81146 1/2018 Ver. 1...
- Page 3 REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN AUTHORIZED AND CERTIFIED DEALER. For the nearest certified dealer, call STANLEY Infrastructure at (503) 659-5660 and ask for a Customer Service Representative. PBCC85 User Manual ◄ 3...
-
Page 4: Safety Symbols
Always observe safety symbols. They are included for your safety and for the protection of the tool. LOCAL SAFETY REGULATIONS Enter any local safety regulations here. Keep these instructions in an area accessible to the operator and maintenance personnel. 4 ► PBCC85 User Manual... -
Page 5: Safety Precautions
STANLEY. Place the added precautions in the space provided on page BATTERIES PBCC85 5.5-Ton cable cutting tool will provide safe and • Only charge batteries with a STANLEY recommended dependable service if operated in accordance with the battery charger. -
Page 6: Tool Anatomy
WHAT IS THE PBCC85 CUTTING TOOL? The PBCC85 is a battery powered 5.5-ton cable cutting tool with a 3.34 inch guillotine style head. The PBCC85 is capable of cutting copper and aluminum up to 1250 MCM and telecom cable up to 3.3 inchs in diameter. -
Page 7: Specifications & Accessories
ACCESSORIES 5 Amp/hour Lithium Ion Battery ........................DC205 5 Amp/hour Lithium Ion Battery 2-pack ...................... DCB205-2 120V AC Charger ............................DCB115 12V DC Charger .............................DCB119 Note: Only use battery chargers recommended by STANLEY. Bucket Bag ................................. BB01 PBCC85 User Manual ◄ 7... -
Page 8: Operation
Press and hold the pressure release to open the cutting head. Note: Release the trigger to immediately stop the tool. Press the pressure release at any time to open the jaws. 8 ► PBCC85 User Manual... -
Page 9: Replacing The Blades
51 - 74% Charged Less than 50% Charged Charge Battery REPLACING THE BLADES DO NOT install or change blades while the battery is connected to the tool. Disconnect the battery BEFORE installing or changing blades. PBCC85 User Manual ◄ 9... -
Page 10: Troubleshooting
Ensure the battery is fully charged. Ensure the blades flashes red after every crimp. are in good condition. If problem persists, have the tool serviced as soon as possible. The tool is leaking hydraulic oil. Have the tool serviced immediately. 10 ► PBCC85 User Manual... -
Page 11: Pbcc85 Parts Illustration
PBCC85 PARTS ILLUSTRATION PBCC85 User Manual ◄ 11... -
Page 12: Pbcc85 Parts List
JAE3940180 Anti-extrusion Ring ACKR0204 Grooved Pin 91465 Strap Ring JAE4500125 Anti-extrusion Ring J3740180 O-Ring 91856 Motor Reduction Unit 77898C Cutting Head Unit See page 14 Reservoir Unit See page 13 Hydraulic Unit 92886 Electronic Device 12 ► PBCC85 User Manual... -
Page 13: Pbcc85 Hydraulic Body Illustration
77803 Release Device J0720190 O-Ring 77805-01 Delivery Valve Unit BILL04.76 Ball 77806-01 Succion Valve Unit J0290178PU70 O-Ring 77848C-02 Spring Collar Unit J4300200 O-Ring 77849C Cam Compartment Unit JAE0500100 Anti-extrusion Ring 77804C Commutator JSR1927205 Wiper Ring PBCC85 User Manual ◄ 13... -
Page 14: Pbcc85 Reservoir Parts List
77009-02 Reservoir Body 77852-DEW Release Lever Unit VAV04CB015 Screw AIG4X29.8BP Calibrated Pin BILL04.76 Ball J0640190 O-Ring 91576 Metal Clamp JAE0700150 Anti-extrusion Ring J0420250 O-Ring ZBINA420 Magnet Pin VAR04W Washer 91232 Release Trigger VAE04 VAV08BP008 Screw 14 ► PBCC85 User Manual... -
Page 15: Pbcc85 Cutting Head
Counter Blade VAV08HB030 Screw 37012DUB Slide Away VAV08HC020 Screw 37018DUB Sleeve 37805C Handle Unit 37037DUB Stop Plate 37025-01 Locking Pin 37011DUB Crossbar AGEM5.20 Elastic Pin VAV04PF Ball Headed Dowel 37031DUB Dowel VAE08HBZ AAET10 Circlip 37016DUB Blade PBCC85 User Manual ◄ 15... - Page 16 STANLEY Infrastructure 6430 SE Lake Road Portland, Oregon 97222 USA (503) 659-5660 / Fax (503) 652-1780 www.stanleyinfrastructure.com...
