The CP Series In-Ceiling and In-Wall loudspeakers will provide long term satisfaction in terms of
sound quality and reliability provided they are installed correctly, according to the instructio ns and
conditions contained in this manual. Please read this installation guide carefully before proceeding. We
assume the installer is trained and skilled in the correct and safe use of hand and power tools and has a
working knowledge of local building and fire regulations/codes as well as experience of the
conditions/services behind walls and ceilings into which these speakers will be installed.
ABOUT YOUR ABILITY TO INSTALL THESE PRODUCTS SAFELY AND CORRECTLY PLEASE CONTACT YOUR
LOCAL AUTHORISED MONITOR AUDIO DEALER OR CUSTOM INSTALLER.
WARNINGS:
A minimum depth of 190mm (7½ Inches) is required for the In-Ceiling back box to fit into recess. The
In-Wall requires 98mm (4 Inches)
The fixing clamps require a minimum of 25mm (1 Inch) of surface area around the cut-out hole to ensure
a secure fixing!
The fixing clamps will operate on ceilings or walls with a minimum thickness of 9mm (3/8 Inches) to a
maximum depth of 32mm (1¼Inches)
Do not attempt to fix these speakers to your ceiling or wall if you are unsure of your ability to provide a
secure and safe fixing. IF IN DOUBT CONTACT YOUR LOCAL AUTHORISED MONITOR AUDIO
DEALER OR CUSTOM INSTALLER.
Ensure that there are no water pipes, air ducts or electricity cables running immediately behind the cut
out area!
Please work from secure steps or scaffold and avoid trailing wires for your safety and those around you.
Always turn off the amplifier or other devices in the system when connecting these speakers
IMPORTANT INFORMATION
www.monitoraudio.co.uk
IF IN DOUBT
1
