13. Attach the Left Handlebar Cover (109) to the Console
(5) with three M4 x 16mm Screws (66). Attach the
Right Handlebar Cover (110) in the same way.
See assembly step 11. Tighten the eight M6 x 16mm
Tapered Button Screws (107).
14. Plug the Power Cord (96) into the Power Socket (140)
at the rear of the elliptical exerciser.
15. Make sure that all parts of the elliptical exerciser are properly tightened. Note: Some hardware may be
left over after assembly is completed. To protect the floor or carpet from damage, place a mat under the ellip-
tical exerciser.
The elliptical exerciser is now fully assembled. If you have purchased the optional chest pulse sen-
sor (see page 21), follow the instructions on page 21 and install the receiver included with the chest
pulse sensor.
13
110
109
66
66
14
10
5
96
140
