Pro-Form PFEL05807.0 User Manual page 6

1.
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.
While a second person tips the Frame (2)
backward, attach a Wheel (25) to each side of
the Frame with an M10 x 35mm Shoulder
Screw (94).
2. Carefully tip the Frame (2) onto its side. Orient
the Base (1) as shown, and then insert the
Base into the Frame. Attach the Base with two
M10 x 62mm Button Bolts (97), two M10
Spacers (76), two M10 x 48mm Button Screws
(78), and two M10 Split Washers (72).
Then, carefully tip the elliptical exerciser to an
upright position.
1
2
6
2
25
94
2
1
76
72
97
78
