SECOLink BP2 Installation Manual page 4

Intruder alarm system
SUPR - each wireless detector is supervised by a check-in signal that is sent to the receiver. The period of detector sending check-in signal is 1
Technical information
hour. Supervisory is expressed as percentage values, measured while system is armed.
--------------- SUPR RSSI BAT T
RSSI - Received Signal Strength Indicator is a common name for the signal strength in a wireless network environment. It is a measure of the
Living room 100% 98% 3.60V
1 power level that a RF client device (control panel/module) is receiving from an access point (detector). RSSI is the relative signal strength in a
Bedroom 100% 99% 3.54V
2 wireless environment and it is expressed as percentage values between 1-100. The information how the detector „see" the panel/module in the
wireless network can be found in ALARMSERVER.NET ( collumn RSSI, wl ).
BATT - the battery voltage is the average voltage of last six measurements when detector is sending the information to receiver.
threshold voltage < 2,45V.
Due to the fact that there may be changes in the passive environment after installation, it is possible to temporarily attenuate the radio frequency link during installation or
maintenance. In order to temporarily attenuate the radio frequency link change the setting Attenuation as described below:
Service mode
System setup
1
System setup
Wireless settings
7
Change setting's Attenuation value to 3dB. Save
Wireless settings
changes by pressing the [ENT] key.
1 Attenuation 0dB
Caution: Each wireless detector is supervised by a
check-in signal that is sent to the receiver at 60
Wireless settings minutes interval. During this check-in commu-
1 Attenuation 3dB nication the detector will receive new settings and
will start to work according to them. DO NOT
FORGET to change the Attenuation setting's value
Wireless settings
to 0dB when installation or maintenance works are
Attenuation 3dB
1
finished.
ALARMSERVER.NET is an online platform for alarm systems installers and end users.
see the consist of the system, installed device serial number and firmware versions. He can also remotely monitor alarm systems technical status (supervisory statistic, RSSI on
control panel or detector side, battery status, activity), see the triggered alarms and troubles. This information allows the installer to more precise identify the possible troubles in
the system, before taking actions and going to site. Security system devices send its status and technical information automatically or manually by request.
This system is designed to work with
have a "best before" date printed on their packaging or on the batteries themselves. Buy batteries that have a "best before" date of two years
or more from your purchase date. Battery life of wireless detectors depends on the environment, usage, and the specific wireless devices
being used. Factors such as humidity, high or low temperatures, as well as large swings in temperature may all reduce the actual battery life
in a given installation. When the battery is nearly dead
the alarm system for the user to replace it before it discharges completely.
1. Unscrew the self-tapping screw.
2. Remove the detector's top cover.
3. Observe correct polarity and insert the battery into the battery holder.
4. Close the top cover and secure it with a self-tapping screw.
5. Dispose of used batteries as per local regulations.
Caution: the detector will send a tamper message to the receiver when housing is opened - the alarm can be triggered.
Kodinis Raktas UAB, manufacturer of SECOLINK Intruder Alarm System, offers a Warranty for a term of twenty-four months. It declares, that product BP2 complies
with essential EU directives and EU standards EN 50131-1, Grade 1, Environmental Class II; EN 50131-2-2. For more information visit manufacturer's website
www.kodinis.lt or www.secolink.eu for a complete text of declaration. SECOLINK Intruder Alarm System is designed and manufactured in Lithuania.
Please act according to your local rules and do not dispose of your unusable alarm system or its components with other household waste. This product utilization in
EU is covered by European Directive 2002/96/EC.
Page 4
TECHNICAL INFORMATION (SUPERVISORY, RSSI, BATTERY VOLTAGE)
IMMUNITY TO ATTENUATION
SERVICE PLATFORM ALARMSERVER.NET
BATTERY INSTALLATION/REPLACEMENT
Lithium battery ½ AA, 3,6V battery. Do not install any other type. Use fresh batteries. Most batteries
(low battery threshold voltage < 2,45V)
SYSTEM COMPLIANCE AND WARRANTY
Temporarily
attenuated signal
during installation or
Normal signal maintenance
This platform requires the installer to log in to gain access to the page.
, the detector will send a low battery signal
BP2, BP2-p Wireless detector
Installation manual
Low battery
Normal signal
The installer can
to
Rev.18/12/17_KF_Sert
