SECOLink BP2 Installation Manual

Intruder alarm system
The BP2 or BP2-p detector provides the
or with built-in virtual modules EXT116SVM in P series control panels P16, P32 and P64.
Model Passive infrared sensor (PIR sensor)
BP2 Wide angle array
BP2-p Pet immune array
Dimensions (W x H x D)
54,8 mm x 100 mm x 39 mm
1
2
3b
Use for swivel mount bracket
To change a lens, release the lens cavity
smooth side facing outwards. Verify that the lense name is located at the top of the lens before snapping the cavity cover back into place.
1
Lens array type
reliable, convenient and cost effective solution for security
SECOLINK WIRELESS DETECTORS
Ambient temperature Ambient humidity
o o
0 C - +55 C 0% - 70%
2
1
cover by simultaneously pressing the plastic supports (1) to the direction as shown in picture. Gently
Wide angle array
(BP2)
15m
WA 0.9 GI 6 T1
10
5
1
0
5
10
0 5
15m
2,1m
0 1,9 3,3 5,9
protection.
Built-in temperature sensor
SPECIFICATIONS
Operating frequency
Depends on firmware version of the detector:
1 = 868,30 MHz (EU)
9 = 915,30 MHz (AU)
INSTALLATION
3
Detector's recommended mounting
height is 2,1 meters (+/- 20 cm). It is
designed to be mounted on surfaces, in
corners (3a), or installed in places where
it is necessary to use a swivel mount
bracket (3b).
Find a suitable location (place) for the
detector keeping in mind the warnings
below:
Keep away from heat source.
Do not expose to air drafts.
Do not install outdoors.
Do not obscure partially or completely
the detector's field of view.
Avoid direct sunshine.
Keep away from power cables.
Mount on solid and stable surface.
CHANGING THE LENSES
Long range array
(optional for BP2)
15m
10
5
o
98 0
5
10
10 15m 0 5
15m
2,1m
15m 0 1,8 3,3 5
BP2, BP2-p Wireless detector
The detector is compatible with wireless extension modules EXT116S
Long range array
Not available
Battery
Lithium battery
½ AA, 3,6V
3a
Corner mount
4
LED
Remove the isolation tab. Follow the instructions on a
2nd page and enroll the detector into the system. After a
successful detector's enrollment close the top cover.
Use the screw to secure the top cover to the mounting
base.
fix the new lens into place with the
15m
(LR 0.9 GI 6 T1)
10
5
0
5
10
10 15 20m
15m
2,1m
8,4 20m 0
Installation manual
Optional
Battery life
~2 years
Surface mount
LED ON
O
LED OFF
Pull the
isolation tab
Pet immune array
(BP2-p)
(WP 0.9 GI 6 T1)
o
95
0 5 10 15m
2,1 4,8 8,6 15m
Page 1
