SECOLink BP1 Installation Manual

Intruder alarm system
The BP1 detector provides the mo st reliable,
toughest, most labor intensive installation. The BP1 detector is compatible with wireless extension modules EXT116S or with built-in virtual modules EXT116SVM in P series control
panels P16, P32 and P64.
Model Passive infrared sensor (PIR sensor)
BP1
Dimensions (W x H x D)
59 mm x 110 mm x 46 mm
1
2
1
4
Assembly of the swivel mount
bracket pad
Tighten one part of the bracket to a wall, place detector's
bracket guide on the detector, and secure everything
with a screw. Make sure that the angle between a wall
and detector's body meets the requirements.
DETECTION PATTERNS
Top view
o
78
Side view
2,1 m
1,9 m 3,3 m 5,9 m
Make sure that the angle between a wall and detector's
body meets the requirements.
convenient and cost effective solution for security
SECOLINK WIRELESS DETECTORS
Ambient temperature Ambient humidity
o o
0% - 70%
-10 C - +55 C
2
5
Alignment pins
o
~7
Remove the plastic tab. Follow instructions on a 2nd
page and enroll the detector into the system.
BATTERY INSTALLATION/REPLACEMENT
Battery life of wireless detectors depends on the
environment, usage, and the specific wireless devices
being used. Factors such as humidity, high or low
temperatures, as well as large swings in temperature
may all reduce the actual battery life in a given
installation. When the battery is nearly dead, the
detector will send a low battery signal to the alarm
system for the user to replace it before it discharges
completely.
1. Unscrew the self-tapping screw.
2. Remove the detector's top cover.
3. Observe correct polarity and insert the battery into
the battery holder.
4. Close the top cover and secure it with a self-tapping
screw.
5. Dispos of used batteries as per local regulations.
Caution: the detector will send a tamper message to the
receiver when housing is opened - the alarm can be
triggered.
15 m
protection. The device is powerful and versatile enough to help solve even the
Built-in temperature sensor
SPECIFICATIONS
Operating frequency
Depends on firmware version of the detector:
1 = 868,30 MHz (EU)
9 = 915,30 MHz (AU)
INSTALLATION
2
1
Pull the
plastic tab
2
1
BP1 Wireless detector
Installation manual
Pet immunity
Battery
Lithium battery BP1: > 2 years
½ AA, 3.6V
3
Use for swivel mount bracket
6
Close the top cover after a successful detector's
enrollment into the alarm system. Use the supplied self-
tapping screw to secure the top cover to the mounting
base.
WIRELESS DETECTOR OPERATION TESTING
Normally a wireless motion detector idles 4 minutes after
last movement detection:
~ 4 min
To test wireless detector operation enable the test mode
by doing a burglary zone test:
Main menu Test Burglary zone test
Detector will enter the test mode after first movement
detection and will stay in this mode until the zone test will
end (see picture below).
TEST
STARTED
< 4 min ~ 10 sec
TEST
ENDED
~ 10 sec
Battery life
~ 4 min
~ 4 min
