SECOLink BP2 Installation Manual page 3

Intruder alarm system
KM24G keypad:
BP2 has a built-in temperature sensor. Measured temperature value could be seen at the bottom bar
10/02 +21°C 14:15
of the KM24G keypad, in menu Technical info (for KM24 or KM24A keypads), in SMS (together with a
READY TO ARM
system status information), in application SECOLINK PRO and in a service platform
www.alarmserver.net . The temperature is measured even if the detector BP2 is programmed as
1st Floor
motion detector.
2nd Floor
+21°C
Living room
Bedroom +22°C
KM24, KM24A keypad:
Technical information
-----------------------------Temp
1 Living room +21C
Bedroom +22C
2
Along with the motion detection, the detector can also be programmed as temperature zone.
Service mode
Temperature zone could trigger the technical alarm or can be programmed to silently trigger a PGM
1 System setup
output (attribute No alarm should be enabled) when the measured temperature value reaches the
programmed threshold. Use the 180 enrolling ID number to program the BP2 temperature sensor in
System setup the system.
Zones
3
Enter wireless detector loop (zone) ID number and press the [ENT] key to start enrolling. When
Z01 Living room
enrollment has started, immediately press the tamper switch for a short period of time (~1 sec).
WL det. loop (zone) ID 180
4
Z01 Living room
6 Definition 24h High temper
Used for 24h High temperature or 24h Low temperature. Enter the temperature. Use [Ѓ] or [‚] to change temperature sign (+ or -). Note:
Z01 Living room
temperature field will be visible if wireless detector is in use.
Temperature +23 C
8
Used for 24h High temperature or 24h Low temperature. A zone with this attribute will not trigger an alarm, but can start PGM action.
Z01 Living room
10 No alarm Yes
Useful information:
Use PGM definition Zone violation too keep the output turned On or Off while temperature zone is violated.
Length value should be 0 seconds/minutes. The output will go to previous state when zone will restore.
When motion is detected, the detector will transmit to the receiver and will then go to sleep mode for 4 minutes. If motion is detected again during the sleep time, the unit will not
transmit the event to the receiver. The detector will thus remain in the sleep mode until 4 minutes after the first motion detected was transmitted. The detector will transmit detected
motion every 4 minutes.
~ 4 min
To test wireless detector operation enable the test mode by doing a burglary zone test:
Main Menu
Settings
1
2 Test
3 Event Log
Controls
4
Service Mode
5
Test
Burglary zone test
1
Jutiklis įeis į testavimo režimą, tik kai bus išsiųstas pirmas suveikimas ir liks šiame režime kol zonų testas bus vykdomas iš valdymo pulto.
Zones:
Living room
1
Testing zone is violated (passed test).
Zones:
1 Living room #
TEST
STARTED
~ 4 min
or less
When performing a zone test, the detector must be left idle for 4 minutes before testing can be performed. Once 4 minutes has passed, create motion in front of the detector to see
if the device is both detecting motion and transmitting to the receiver. When motion is detected (#) the detector will go to sleep only for ~ 10 seconds. The short sleep time allows to
adjust the best range of view. To end testing press [ENT].
TEMPERATURE SENSOR
WIRELESS DETECTOR OPERATION AND TESTING
~ 4 min
~ 10 sec ~ 10 sec
BP2, BP2-p Wireless detector
SECOLINK PRO:
Zone should be checked in PGM triggering sources, the setting Pulse
TEST
ENDED
Installation manual
~ 4 min
Page 3
