3
I
NSTALLING
1
Insert the rectangular end of the USB cable into the USB port on your computer (or USB
hub). A green power (PWR) LED illuminates on the modem, indicating that power is on.
The ADSL and USB LEDs also illuminate.
USB hub or
PC USB port
Do not make this connection
until instructed to do so
Windows automatically discovers the modem and completes the installation. The software
sets up the PPP over ATM connection requirements. The connection for your modem can
be one of the following: G.lite or G.dmt (full rate). The installation CD is based on the
features purchased by the customer.
2
If prompted, insert the CD into the CD-ROM drive and click
CD, Click
OK
and go to Step 3 of this section.
3
If you do not insert the CD, the
prompts you to insert the Windows CD. In the
files from
box, type the path for the directory containing
the following files: ATMUI.DLL, ISDNUI.DLL,
ISDN.HLP, and NDISWAN.VXD. The default
directory is
c:\windows\options\cabs
4
Click
to continue.
OK
5
When the System Settings Change dialog displays, click
M
S
ODEM
OFTWARE
Copying Files
dialog
Copy
.
ADSL
USB
skyrocket
Status LEDs
. If you do not have this
OK
to restart your computer.
Yes
Power LED
