Dynojet POWER COMMANDER V Installation Instructions page 4

FIG.D
FIG.E
FIG.F
Ground wire
20-001 www.powercommander.com
7 Plug the PCV wiring harness in-line of the stock wiring harness and injector
(Fig. D).
8 Plug the PCV wiring harness in-line of the stock TPS connectors (Fig. E).
9 Use one of the mounting bolts for the ignition coil to attach the ground wire for
the PCV (Fig. F).
The coil is on the right hand side of the bike behind the radiator.
10 Reinstall the front number plate, fuel tank, and seat.
2008-2014 Suzuki RMZ450 - PCV - 4
