- Page 1 ES-1008PH V2 /GS-1008PH V2 Quick Installation Guide 02-2017 v1.0...
-
Page 2: Package Contents
Model No. ES-1008PH V2: 8-Port Fast Ethernet Switch with 4 PoE+ Ports GS-1008PH V2: 8-Port Gigabit Switch with 4 PoE+ Ports Package Contents Before you start using this product, please check if there is anything missing in the package, and contact your dealer to claim the missing item(s):... - Page 3 I-2. Hardware Overview Front Panel: Please refer to the following description for the front panel: ES-1008PH V2 GS-1008PH V2...
- Page 4 DIP Switch Definition: The front pnael of PoE+ switch provies four pins DIP Switch. The detailed descriptions are shown nin the following table. DIP Switch Status Description This mode makes the PoE Port 1~2 (Extend) operate at auto-negotiation 10Mbps speed duplex mode only, but the delivery distance of PoE power and network data can reach 200m.
-
Page 5: Operating Environment
After installing the switch, you can check its status from the LED inducators on the front panel shown below. LED Definitions: Color LED Status Description Switch is on. Power Green Switch is off. Connected to 10/100M network (Supports ES-1008PHE V2 only) Connected to 10/100/1000M network. - Page 6 - Do not place objects on top of the unit. - Do not obstruct any vents at the sides of the unit. - Do not position the unit close to any heating source such as a heater, radiator or in direct exposure to sun. - Take care to ensure the unit does not come into contact with water.
-
Page 8: Troubleshooting
TROUBLESHOOTING 1. Power LED is not lit. Check if the power cord is properly connected to the external power adapter and the power source. Make sure the DC power jack is firmly plugged into the power socket of the switch. 2. -
Page 9: Federal Communication Commission Interference Statement
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 10 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1995/5/EC, 2009/125/EC, 2006/95/EC, 2011/65/EC. Français: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 1995/5/CE, 2009/125/CE, 2006/95/CE, 2011/65/CE. Čeština: Toto zařízení...
-
Page 11: Declaration Of Conformity
Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directives. Equipment: ES-1008PH V2 8-Port Fast Ethernet Switch with 4 PoE+ Ports GS-1008PH V2 8-Port Gigabit Switch with 4 PoE+ Ports Model No.: ES-1008PH V2 / GS-1008PH V2...
