NOTE: 1. Multiple RFRTAG commands are allowed in the same
form but the same DFn field cannot be defined multiple
times.
2. The DF field length is restricted to 64 bits and must be a
multiple of 8 bits. The sum of all field lengths must be equal
to the tag size.
3. The first field always start at the MSB bit. The bit length
of a field dictates the start bit of the next field, etc. As a
result, DF fields will not overlap each other.
4. RFRTAG does not allow incremental fields (with the "I"
prefix).
5. 432 in the ~CREATE line specifies a 6 inch label.
Use 144 for 2 inch labels and 288 for 4 inch labels.
Example
Same as Example 4 on page 29, except the increment
is dynamic and the result is merged into Alpha to print
on the smart label.
~CREATE;SGTIN–64;432
RFWTAG;64
2;B;*10*
3;D;*5*
14;D;*15383*
20;D;*123456*
25;IDF1;H
STOP
RFTAG;64
64;DF2;H;
STOP
ALPHA
IAF1;16;3;12;0;0
STOP
512 to identify the field
number of this particular
field.
format A letter specifying the
representation format of
the field data.
B – binary, D – decimal,
H – hexadecimal
/Header
/Filter Value
/EPC Manager Index
/Object Class
/Serial Number
RFRTAG
