Chapter 2
RFID PGL Commands

RFRTAG

Purpose
Mode
Format
30
~CREATE;SGTIN–96;432
RFWTAG;96
8;B;*00110000*
3;D;*5*
3;D;*6*
20;D;*123456*
24;D;*7777777*
38;D;*123456*
STOP
END
~EXECUTE;SGTIN–96;1
~NORMAL
To read the content of an RFID tag (embedded in a
smart label) into a dynamic field. This command cannot
be mixed with the RFREAD command.
CREATE
RFRTAG; size
( Bit Field )+
STOP
RFRTAG Specifies the RFRTAG command, enter
RFRTAG;
size A decimal number specifying the overall
bit length of the RFID tag.
Bit Field A line description of a bit field; must have
one of the following syntax formats:
length ;DF n ; format
length
DF n
/Header
/Filter Value
/Partition
/Company Prefix
/Item Reference
/Serial Number
A decimal number
specifying the bit length
of a field within a tag. The
maximum length is 64
bits.
Indicate dynamic data
field to store the read
result. Replace n with a
number ranging from 1 to
