Centronics Interface Parameters - Printronix L1024 Setup Manual

Centronics Interface Parameters

Host Interface
Centronics
Data Bit 8
Disable
Enable *
Paper Inst
Pol
Standard *
Inverted
Configuring the Printer
Dataproducts Serial
(page 3–36) (page 3–39)
Paper Data
Inst Line Polarity
Disable * Standard *
Enable Inverted
Strobe Fast
Filter Busy
Enable * Enable *
Disable Disable
Figure 3–9. Centronics Interface Menu
Strobe Output
Polarity Polarity
Standard * Standard *
Inverted Inverted
Trailing
Edge
Enable
Disable *
Press UP, DOWN, NEXT, and PREV
to view options.
Press ENTER to select an option.
Press ON LINE at any time to exit
configuration (will save changes until
printer is turned off).
* = Factory Default
3–33
