Escape Sequence:
Hexadecimal:
Set Line Spacing to n/216"
Sets the line spacing to n/216 of an inch per line. 0 n 255. Overrides the "Lines/Inch" value in the forms
menu.
NOTE: The actual resolution of the printer's paper stepper motor is 1/288 of an inch. When spacing is
specified in 1/216 of an inch, the printer will actually move paper to the nearest 1/288 of an inch.
Example: The following escape sequence will set line spacing to one half inch.
Escape Sequence:
Hexadecimal:
Set Line Spacing to n/72"
Sets the line spacing to n/72 of an inch per line. 0 n 255. Since the distance between print head wires is
1/72 of an inch, this is equivalent to setting n wire spacing. Overrides the "Lines/Inch" value in the forms
menu.
Example: The following escape sequence will set line spacing to 8/72 of an inch, for use with eight wire
graphics.
Escape Sequence:
Hexadecimal:

Horizontal Position

Carriage Return
Causes the current line to be printed, and then sets the current print position to the left margin. If "Auto LF"
is set to "On" in the interface setup menu, a line feed will also be performed.
Control code:
Hexadecimal:
ESC 2
1B 32
ESC 3 108
1B 33 6C
ESC A 8
1B 41 08
CR
0D
ANSI X3.64 Emulation
ESC 3 n
ESC A n
CR
31
