WL1837MODCOM8I WLAN MIMO and Bluetooth
The WL1837MODCOM8I is a Wi-Fi
the TI WL1837 module (WL1837MOD). The WL1837MOD is a certified WiLink™ 8 module from TI that
offers high throughput and extended range along with Wi-Fi and Bluetooth coexistence in a power-
optimized design. The WL1837MOD offers A 2.4- and 5-GHz module solution with two antennas
supporting industrial temperature grade. The module is FCC, IC, ETSI/CE, and TELEC certified for AP
(with DFS support) and client. TI offers drivers for high-level operating systems, such as Linux
Android™, WinCE, and RTOS.TI.
......................................................................................................................
