- Page 1 ® CY3280-CPM1 CapSense Plus Module Development Kit Quick Start Guide Doc. # 001-51974 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): 408.943.2600 http://www.cypress.com...
- Page 2 1. Kit Contents ® Each CY3280-CPM1 CapSense Plus Module Development Kit contains: CY3280-CPM1 CapSense Plus Module Board ■ CY3280-CPM1 Kit CD ■ Quick Start Guide ■ Universal CapSense Module boards are available for purchase separately. For more information, visit http://www.cypress.com/shop.
- Page 3 This section uses one example firmware to demonstrate the setup of CY3280-CPM1 with CY3280-20x45 Universal CapSense Controller board. Similar procedure is followed for the CY3280-28xxx board. Refer to the CY3280-CPM1 kit guide for more examples. 4.1 Real Time Clock (RTC) Setup Connect the CY3280-CPM1 board to the CY3280-22x45 Universal CapSense Controller board's P2 receptacle connector.
- Page 4 For knowledge base articles, customer forums, and online application support, visit www.cypress.com/support. ©2009-2011 Cypress Semiconductor Corporation. PSoC and CapSense are registered trademarks of Cypress Semiconductor Corp. All other trademarks or registered trademarks referenced herein are property of the respective corporations.
- Page 5 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Cypress Semiconductor CY3280-CPM1...
