Summary of Contents for Calor De Hogar NTC-60

  • Page 1 Calor de Hogar Av Tecnológico 735, PB San Salvador Tizatlalli Metepec, 52172, Edo de México Teléfono (722) 216 3330 (55) 1163 6038 www.calordehogar.com servicio@calordehogar. v e n t a s Í c a l o r d e h o g a r...
  • Page 2 CONTENT Content--------------------------------------------------------1 Introduction --------------------------------------------------2 Chapter 1 Parameters -----------------------------3 Chapter 2 Installation and Cautions -------------5 Chapter 3 Functions and Operation ------------12 Chapter 4 Maintenance --------------------------14 Chapter 5 Troubleshooting ----------------------15 Chapter 6 Warranty and Service ----------------16...
  • Page 3: Introduction

    INTRODUCTION Thank you for choosing NTC series steam generator with well-designed structure, steady performance and convenient installation. To form the whole set of steam bathing equipment, you need a personal steam bathing room as well. The steam generator is designed to remove tiredness, relax muscles and stimulate blood circulation.
  • Page 4: Parameters

    Heating Power dimension Model elements Voltage(V)/Current (A) (kW) (length*Width*height)(in.) (N*kW) NTC-45 3*1.5 240/18.6 NTC-60 3*2.0 240/25 NTC-90 6*1.5 240/37.5 NTC-120 12.0 6*2.0 240/50 Table 1 Figure 1 1. Frame 2. Service panel for water level sensor 3. Auto drain motor 4.Drainage valve 5.Connector 6.T-pipe...
  • Page 5 The Schematic diagram of the steam generator: CONTROLLER MAIN PCB FUSE SIDE-BOARD TERMINAL (RELAY) AC240V 60Hz POWER SUPPLY 1.Steam Outlet 2.Water Level Sensor 3.Temp Switch 4.Heating Elements 5.Inlet Valve 6.Drainage Outlet 7.Drainage Valve 8.Terminal 9.Side-Board(Relay) 10.Main PCB 11.Control Panel 12.Water Tank 13.Safety Valve Figure 2 2.
  • Page 6: Installation And Cautions

    NT-200 controller Set temp indicator Temp display Set time indicator Connector 2 P NT-200 Teat preserving Heating indicator indicator Heat Preserving TEMP TEMP TEMP TIME TIME TIME Nature Power button STEAM BATH CONTROL Adjust button LIGHT PAUSE Pause button Connector 6 P Time,temp set button Light button Figure 3...
  • Page 7 correct steam generator model and size are as critical as design of the steam room itself. The power supply and circuit protector should be carefully checked to match the parameters of the generator. Please referring to the table below and select the suitable model for your specification. Power Room size Fuse or breaker...
  • Page 8 Caution: The control wire and temperature wire should not be parallel to or intersect with the power wire. The temperature sensor should not be installed on the side of the wall which is behind the door when the door is opened and the controller should not be installed in any moist place. Install in the roof CONTROL WIRE T E M P S E N S O R W I R E...
  • Page 9  No block valve should be installed in the steam pipelines. Strictly no blocked or blended pipe, otherwise have negative affect on the flow of steam and condensate. The steam pipelines should be installed with a slight angle so that the condensate can flow back to the generator or the nozzle.
  • Page 10 Flexible stainless steel hose Figure 7 5. Electrical installation Caution:  All electrical should be installed by licensed electricians and conform to local and national codes.  Power supply must be cut off before installation, maintenance and repair. Press the on/off button on the generator cannot cut power from the supply.
  • Page 11  The selection of fuse and breaker must strictly follow the data in table 3.  Choose the suitable power wire according to table 3 and local codes. Take off the service cover of the generator, insert the 3-core power wire (single phase, 240V, 60Hz ) into the hole at the back of the generator case and connect to the correct terminal.
  • Page 12 ZQJ0806 No 100615 SENSOR Water level Probe LAMP D VALVE IN VALVE TEST POWER IN JUMP LAMP 12 0V DRAINAGE SUB-BOARD VALVE INLET ZQJ-FB4.PCB VALVE CONTROLLER HEATING ELEMENTS TEMP SWITCH TERMINAL CIRCUIT DIAGRAM NTC-45,NTC-60 L1 240VAC60Hz L2 240VAC60Hz Figure 9...
  • Page 13 DRAIN HIGH ZQJ0806 No 100615 MAIN BOARD WATER LEVEL ZQJ0806 No 100615 Water level Probe SENSOR LAMP D VALVE IN VALVE TEST POWER IN JUMP LAMP 12 0V DRAINAGE VALVE SUB-BOARD INLET VALVE ZQJ-FB6.PCB CONTROLLER HEATING ELEMENTS TEMP SWITCH TERMINAL CIRCUIT DIAGRAM NTC-90,NTC-120 L1 240VAC60Hz L2...
  • Page 14: Functions And Operation

    CHAPTER 3 FUNCTIONS AND OPERATION 1. DISPLAY PANNEL Temperature: The LCD will display the temperature measured by the temperature sensor in the range of 43℉~140℉. Set temperature: The temperature setting range is 95℉~131℉ and indicated by the 5 red LEDs besides the LCD. The bottom LED is on when temperature is 95℉; the bottom two LEDs are on when the temperature is within range of 97℉~104℉;...
  • Page 15 a) For models with two groups of heating elements (1~6 elements): if the indicator is red or green, then the actual temperature is below the setting value and both two groups of heating elements are working; if the indicator is blue, then the actual temperature is 4℉ higher than the setting value so only one group of heating elements is working.
  • Page 16: Maintenance

    Press this button again to resume. LIGHT: Switch for the external light. The button can be used as the switch for the external light as long as the system is connected to power supply. The LED is on when the light is turned on. ▲...
  • Page 17: Troubleshooting

    generator completely cools down. Label the three wires which connect the upper part of the main board to the water level sensor and the source, drain pump, electromagnetic drain valve and water inlet electromagnetic valve in the bottom part of the main board. Unplug these wires and remove the main board (be careful with yellow-green ground wire under the screws of the circuit board).
  • Page 18: Warranty And Service

    Connection error between control Check the connection wire and connectors panel and main board. between the control panel and the main board. Automatically draining when setting time is up or ON/OFF button is Normal pressed. Automatically shut down after draining for a few minutes Table4 Diagnosing procedure: 1.
  • Page 19  Damage caused by accident, misusing of chemistry products, or any other reason which are beyond our company‟s responsibilities will not be covered. Any product whose label, nameplate has been removed, altered, damaged is not covered either.  Using in a salty environment or any other extreme, corrosive condition is not covered by the warranty.
  • Page 20 Calor de Hogar Av Tecnológico 735, PB San Salvador Tizatlalli Metepec, 52172, Edo de México Teléfono (722) 216 3330 (55) 1163 6038 www.calordehogar.com servicio@calordehogar. v e n t a s Í c a l o r d e h o g a r...
