- Page 1 Speech Dialler Installation Manual ukpanels.com THANK YOU FOR VOTING TEXECOM Installation Manual Voice & Text Dialler...
- Page 2 Speech Dialler Installation Manual ukpanels.com 1. Overview Introduction Mobile Network Contact 1 Service Centre Contact 2 Contact 3 Contact 4 Telephone Auxiliary Input Contact 5 Aux (4) ..Ready..Intruder (3) PA (2) Fire (1) pqrs wxyz Telephone Contact 6 Speech Dialler...
- Page 3 Inputs: The Speech Dialler has four trigger inputs; each input can be assigned a voice message and/or a text message. The trigger inputs are normally connected to the alarm control panel communicator outputs or bell output.
- Page 4 Speech Dialler and using the Remote Access feature. Memo: The Speech Dialler has a memo feature, which allows you to record up to 32 seconds of audio. The memo feature can be accessed locally at the unit or remotely using a touch-tone telephone.
- Page 5 2. Installation General The Speech Dialler requires a 12V @100mA DC power source, which is normally supplied by the auxiliary power output of an intruder alarm control panel. If the unit is not connected to an alarm control panel then a suitable power supply will be required.
-
Page 6: Pcb Layout
Trigger Inputs and power supply connections (SELV) & Loudspeaker connector (SELV) Connection terminals on the Speech Dialler are described as either “Safety Extra Low Voltage” circuits (SELV) or “Telecommunications Network Voltage” circuits (TNV). • It is important that the TNV connections are only connected to the PSTN, and SELV circuits are only connected to other circuits designated as SELV circuits •... - Page 7 These terminals should be connected to the relevant outputs on the alarm control panel. When the input is triggered the Speech Dialler will initiate the calling sequence and play the relevant speech and/or text message. The diagram below show the...
- Page 8 Speech Dialler Installation Manual ukpanels.com Control Panel Connection Table The table below shows connection details for various alarm control panels: Trigger Inputs Trigger Control Panel +12V Polarity Fire Intruder A1 Advantage Bell - Aux + Aux - ADE Accenta 6...
- Page 9 Speech Dialler Installation Manual ukpanels.com Connections to the Telephone Line The easiest way to connect the Speech Dialler to the telephone line is to use the telephone lead that is provided with the unit as shown below: Black Yellow Standard BT telephone plug...
-
Page 10: Specifications
Re-apply mains power to the control panel and reconnect the battery. The Speech Dialler will enter its initialisation mode (15 seconds), to load the factory default parameters press the red record key 5 times then the... - Page 11 As a result the Speech Dialler is covered by a two-year warranty against defects in material or workmanship. As the Speech Dialler is not a complete alarm system but only a part thereof, Texecom cannot accept responsibility or liability for any damages whatsoever based on a claim that the Speech Dialler failed to function correctly.
- Page 12 Texecom Limited, Bradwood Court, St. Crispin Way, Haslingden, Lancashire BB4 4PW, England. Technical Support: Tel: +44 (0)1706 234833 Tel: +44 (0)1706 234811 Fax: +44 (0)1706 213187 © TEXECOM LTD. 2000 - 2003 INS232...
