Summary of Contents for Texecom Azura 360
-
Page 2: Table Of Contents
Contents Section Page Installation Mounting the Unit Patented Engineer Hold-Off Mode Installing the Unit 1.3.1 Optional “Battery First” Connection Method Installing Multiple Units 1.4.1 SCB Mode Commissioning Servicing Safety Technical Specification Warranty Registered Installer Application Form INS154-4... -
Page 3: Installation
(not the mortar or facing) by at least 40mm into suitable wall plugs. Patented Engineer Hold-Off Mode For safety reasons, each Texecom sounder and strobe unit incorporates a unique patented engineer Hold-Off mode. This mode prevents the unit from self-activating during installation and maintenance, thereby allowing only bona fide engineers access to the unit without any loss of tamper protection. -
Page 4: Optional "Battery First" Connection Method
The following table illustrates how to connect the unit to the Texecom range and other control panels: Texecom Control Panel C&K Active 5, Securit BELL + 24 TAMPER AUX - ST - Menvier TS510, 700, 800 BELL 12V BELL TRIG... -
Page 5: Installing Multiple Units
Installing Multiple Units If more than one unit is connected to an installation, the current demand may exceed the rated current output of the control panel. This can be avoided by selecting the SCB mode on all but one of the connected units. 1.4.1 SCB Mode In this mode the unit draws the majority of its sounding current from the built-in... -
Page 6: Commissioning
Commissioning Most control panels have a method of testing the siren and strobe, which should be utilised for final testing. Failing this, simply arm the system and cause an alarm to confirm correct operation. Temporarily disconnect the positive supply to the unit at the control panel to confirm that the sounder self-activates. -
Page 7: Safety
When the outer cover is replaced, and the tamper circuit is closed, the LEDs will alternate rapidly, confirming that the tamper circuit is secure and signalling that S/A on tamper will be re-enabled within 2 minutes, after which the LEDs will alternate slowly to signal normal operation. -
Page 8: Technical Specification
Plastic bags can suffocate - always dispose of packaging carefully. Technical Specification Environmental Volume Azura 360, Tempest: 109dB Peak at 1m (A Weighting, 90°) Odyssey 1E, 2E, 3E & 4E: 109dB Peak at 1m (A Weighting, 90°) Odyssey 1, 2, 3 & 4: 115dB Peak at 1m (A Weighting, 90°) - Page 9 Physical Material Azura 360, Tempest: 3mm polycarbonate Odyssey 1E, 2E, 3E & 4E: 3mm polycarbonate / 3mm ABS Odyssey 1, 2, 3 & 4: 3mm polycarbonate Orientation Azura 360, Tempest: Vertical or horizontal Odyssey 1, 1E, 3 & 3E: Vertical Odyssey 2 &...
-
Page 10: Warranty
Warranty All Texecom products are designed for reliable, trouble-free operation. Quality is carefully monitored by extensive computerised testing. As a result the Azura 360, Tempest, Odyssey 1E, Odyssey 2E, Odyssey 3E and Odyssey 4E are covered by a two year warranty against defects in material or workmanship (details on request). -
Page 11: Registered Installer Application Form
Registered Installer Application Form Partially Completed Forms CANNOT be accepted. Please use Black Ink and Block Capitals. Name: Position: Company: Fax: Tel: E-Mail: Mobile: Website: Address: Country: Postcode: Which Distributors do you buy from? (Indicate at least one). How many of the following products do you currently install each month? Motion Detectors: Control Panels (Domestic): Perimeter Detectors:... -
Page 12: Technical Support
• Free Product Training* • Latest Product Information Register online at www.texe.com or simply complete the form on the reverse of this page and return it to Texecom to become a Registered Texecom Installer. *Available for UK Registered Installers only.
