Dolphin Power Supply
Advanced Operation (Dolphin X40+):
1. You can program the power supply at any time.
See the relevant section below for more details on each program.
2. If no program is selected, the robot will perform a single cleaning
cycle.
Weekly Timer
Your robot has a Weekly Timer feature that enables
you to set an automatic cleaning schedule for
the week ahead.
When the power supply is switched on, you can press the
Weekly Timer button to select one of the following cleaning
schedule options for the week ahead:
The robot will automatically work every day for a full cycle,
One click
that is, once a day for 7 days.
The robot will automatically work every alternate day for a full cycle,
Two clicks
that is, 4 times in a week.
The robot will automatically work every 3 days,
Three clicks
that is, 3 times in a week.
After selecting one of the above options, the robot will start to operate at the next occurrence
of the programmed start time.
Note: A fourth click will cancel the cleaning schedule program (without a visible indication).
If the robot is working in Weekly Timer mode, the Weekly Timer button constantly blinks between cycles.
At the end of the week, the power supply automatically switches off and you need to reschedule the robot.
Regular/Fast Mode
Your robot has a Fast Mode feature that enables you to select
a fast cleaning cycle instead of a standard cleaning cycle.
When the LED under the Full Cycle icon
When the LED under the Fast mode icon
In this mode, the cycle duration is one hour and the robot cleans the pool floor only.
Note: Once Fast Mode is selected, the robot will continue to work in Fast Mode every time. To revert
to the standard cleaning method, press the button. The LED under the Full Cycle icon will light up.
is lit: The robot will work in the regular manner.
is lit: The robot will work in fast mode.
Smartphone Control
R
Bluetooth Connection
ON/OFF
Weekly Timer
Fast Mode
Delayed Operation
