Bürkert Magnetventil 6013 Operating Instructions

Type 6013
Magnetventil
2/2-Way Solenoid Valve
2/2-Wege Magnetventil
Électrovanne à 2/2 voies
Operating Instructions
Bedienungsanleitung
Manuel d'utilisation
1 OPERATING INSTRUCTIONS
The operating instructions contain important information.
▶ Read the instructions carefully and follow the safety instructions in
particular, and also observe the operating conditions.
▶ Instructions must be available to each user.
▶ The liability and warranty for Type 6013 are void if the operating
instructions are not followed.
1.1 Symbols
▶ Designates an instruction to prevent risks.
→
designates a procedure which you must carry out.
Warning of injuries:
DANGER!
Imminent danger! Serious or fatal injuries.
WARNING!
Potential danger! Serious or fatal injuries.
CAUTION!
Danger! Minor or moderately severe injuries.
Warns of damage to property:
NOTE!
2
2.1 Restrictions
If exporting the system/device, observe any existing restrictions.
2.2 Definition of term
In these operating instructions, the term "device" always refers to the
solenoid valve Type 6013.
english
Address / Adresse
Germany / Deutschland / Allemagne
Bürkert Fluid Control Systems
Sales Center
Christian-Bürkert-Str. 13-17
D-74653 Ingelfingen
Tel. + 49 (0) 7940 - 10 91 111
Fax + 49 (0) 7940 - 10 91 448
E-mail: info@de.buerkert.com
International
www.burkert.com → Bürkert → Company → Locations
Manuals and data sheets on the Internet:
www.burkert.com
Bedienungsanleitungen und Datenblätter im Internet:
www.buerkert.de
Manuel d'utilisation et fiches techniques sur Internet :
www.buerkert.fr
© Bürkert Werke GmbH & Co. KG, 201 - 2017
Operating Instructions 1706/
2 INTENDED USE
Incorrect use of the solenoid valve Type 6013 can be dangerous
to people, nearby equipment and the environment.
▶ The device is designed for blocking, dosing, filling and venting neutral
gaseous and liquid media.
▶ In the potentially explosion-risk area the device may be used only
according to the specification on the separate Ex type label. For use
observe the additional information enclosed with the device together
with safety instructions for the explosion-risk area.
▶ Devices without a separate Ex type label may not be used in a poten-
tially explosive area.
▶ Use according to the permitted data, operating conditions and
conditions of use specified in the contract documents and operat-
ing instructions.
▶ The device may be used only in conjunction with third-party devices
and components recommended and authorised by Bürkert.
▶ Correct transportation, correct storage and installation and careful
use and maintenance are essential for reliable and problem-free
operation.
▶ Use the device only as intended.
3 BASIC SAFETY INSTRUCTIONS
These safety instructions do not make allowance for any contin-
gencies and events which may arise during installation, operation and
maintenance.
Danger – high pressure!
▶ Before loosening the lines and valves, turn off the pressure and
vent the lines.
Risk of electric shock!
▶ Before reaching into the system, switch off the power supply and
secure to prevent reactivation!
▶ Observe applicable accident prevention and safety regulations for
electrical equipment!
Risk of burns/risk of fire!
During continuous operation the surface of the device may become hot.
▶ Keep the device away from highly flammable substances and media
and do not touch the device with bare hands.
▶ Do not obstruct the heat release required for operation.
english
_ _008 / Original DE
3
