Auerswald TFS-Dialog 200 Operation & Installation Manual page 10

Allocation of numbers to the bell buttons 1 -4 (default: 31 – 34)
Only necessary once –
see above on the first
page
Allocation of switching frequencies to the bell buttons 1 -4 (default: 1 – 4)
Only necessary once – see above on the
Allocation of additional door bells to the bell buttons 1 -4 (default: 1, 2, 0, 0)
Only necessary once – see above on the
Setting of the switching time for lighting (default: 0,5 sec.)
Only necessary once – see above on the
Switching on the light during a door call (default number: 8)
Only necessary once – see above on the
Will be activated from the phone by dialling # + above set digits
Dial number 1 -4
of the bell button
first page
first page
first page
first page
Set the target
number
Dial number 1 -4
of the bell button
Dial number 1 -4
of the bell button
Set time between (1 x 0,5 =) 0,5 sec. and
Any series of digits possible (1-6 digits)
Page 10 of 16
Hang up – for more
programming take off
the handset and dial
the internal number of
the TFS-Dialog 200
Dial number 1 -4
for the switching
frequency
Dial number 1 or 2 of
the additional bell
(0 = none)
(9 x 0,5=) 4,5 sec.
