- Page 1 Technical Manual DS-9100 Embedded Net DVR Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
- Page 3 Technical Manual Overview DS-9100 series net DVR is a new generation product designed by HIKVISION. The product combines various patents, along with advanced IT technologies such as video encoding/decoding, embedded system, storage, network and etc. Based on the solid expertise in the fields of digital video surveillance and...
- Page 4 Technical Manual Order Models DS-9104HFI-S, DS-9108HFI-S, DS-9116HFI-S DS-9104HDI-S, DS-9108HDI-S, DS-9116HDI-S Note: 1. The default DVRs are without HDD or CD-R/W. 2. A factory recommended HDD should be used for this device. ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 5: Main Features
Support digital zoom by using mouse when in PTZ control mode Different channels can be set different recording expired time Support normal and event video encoding parameters Support redundant recording Support hard disk group management Support NTP and SADP protocols ©2006 – 2010 by HIKVISION. All rights reserved. - Page 6 Support motion detection, view tampering alert, video exception alert and video loss alert Support privacy mask Support various decoder control protocols and HIKVISION control protocol Support preset, patrol and pattern Support zoom in by clicking the mouse and trace function by dragging...
- Page 7 Others Support front panel, mouse, IR control, special keyboard operation. Support multi-level user management Support kinds of log record and query, including operation, alarm and exception log Network ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 8 Support voice talk and broadcast Build-in WEB Server Development Provide Windows and Linux SDK Provide software source code as demo Provide development support and application system training ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 9 Distributed video accessing businesses, including the global eyes, wide field of vision Networking video surveillance of examination hall Video surveillance of pipelining, workshops and warehouses ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 10: Front Panel
⑥ Function Keys ⑦ Control Keys ⑧ Shuttle Rear Panel ① VIDEO IN, AUDIO IN ② VIDEO SPOT OUT (for video preview only), AUDIO SPOT OUT ③ VIDEO OUT, AUDIO OUT ④ LINE IN ©2006 – 2010 by HIKVISION. All rights reserved. - Page 11 ALARM OUT ⑬ GND, when cascading multiple devices, it is required that grounding through GND first, and then connecting to the protection ground of control keyboard and power input. ⑭ 100~240VAC Power Input ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 12: Specifications
1, RJ45 10M/100M/1000M adaptive Ethernet interface 1 RS-232 interface (for parameters configuration, maintenance, transparent External Serial channel); interface interface 1 RS-485 interface (for PTZ control); 1 RS-485keyboard interface (for special keyboard control) 3, USB2.0 interface ©2006 – 2010 by HIKVISION. All rights reserved. - Page 13 8, SATA interface Hard disk Capacity Each supports more than 2TB capacity 1, RJ45 10M/100M/1000M adaptive Network interface Ethernet External 1 RS-232 interface (for parameters interface Serial interface configuration, maintenance, transparent channel); ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 14 3, USB2.0 Alarm in Alarm out Power supply 100~240VAC, 6.3A, 50~60Hz Consumption(without hard disk) -10℃~+55℃ Working temperature Others Working humidity 10×~90% Chassis 19” standard 2U chassis Size(mm) 450mm(D)×450mm(W)×95mm(H) Weight(without hard ≤8Kg disk) ©2006 – 2010 by HIKVISION. All rights reserved.
