6
J
UMPER
6.1
The jumpers on this MICROSPACE product
6.1.1
COM-A Interfacetyp
RS232C
RS422/485
J19
J19
2-3
1-2
6.1.2
COM-B Interfacetyp
RS232C
RS422/485
J17
J17
2-3
1-2
6.1.3
COM-C Interfacetyp
RS232C
RS422/485
J15
J15
2-3
1-2
6.1.4
COM-D Interfacetyp
RS232C
RS422/485
J13
J13
2-3
1-2
L
OCATIONS ON THE
Interface
RS232C
RS422/485
Interface
RS232C
RS422/485
Interface
RS232C
RS422/485
Interface
RS232C
RS422/485
B
OARD
Connector
used:
J4
J18
Connector
used:
J5
J16
Connector
used:
J6
J14
Connector
used:
J7
J12
18
MSMX104 Manual V1.3
