2.3 Serial COM3, COM4, COM5, COM6 Interface
Features:
- Optimized for use with PC/104 cards
- COM3 – COM6 Interface
- Low-power CMOS
- PC/104 expansion connector
- IRQ3, IRQ4, IRQ9, IRQ10, IRQ11 selectable
- RS422, RS485 selectable as an alternative to the RS232C
Specifications:
Data:
Compatibility:
Driver:
COM-A = COM3:
COM-B = COM4:
COM-C = COM5:
COM-D = COM6:
Data Rate:
Data-Bus:
Cable Type:
Power:
Temperature:
Any information is subject to change without notice.
16C550 UART Controller
16C550 BIOS / DOS
none, supported through standard BIOS
RS232, RS422, RS485
RS232, RS422, RS485
RS232, RS422, RS485
RS232, RS422, RS485
300 Baud - 115k Baud
8Bit
RM2.54mm header
5 Volt +/- 5%
-25° C to +70° C operating
10
