DIGITAL-LOGIC MICROSPACE MSMX104 Technical User's Manual page 17

DIGITAL-LOGIC AG
J1 PC/104 BUS Interface
Pin A:
0
1 IOCHCK
2 SD7
3 SD6
4 SD5
5 SD4
6 SD3
7 SD2
8 SD1
9 SD0
10 IOCHRDY
11 AEN
12 SA19
13 SA18
14 SA17
15 SA16
16 SA15
17 SA14
18 SA13
19 SA12
20 SA11
21 SA10
22 SA9
23 SA8
24 SA7
25 SA6
26 SA5
27 SA4
28 SA3
29 SA2
30 SA1
31 SA0
32 Ground
B: C:
Ground
Ground SBHE
RESET LA23
+5V LA22
IRQ9 LA21
NC LA20
DRQ2 LA19
(-12V) LA18
NC LA17
+12V MEMR
Ground MEMW
SMEMW SD8
SMEMR SD9
SIOW SD10
SIOR SD11
DACK3 SD12
DRQ3 SD13
DACK1 SD14
DRQ1 SD15
REF Ground
SYSCLK
IRQ7
IRQ
IRQ5
IRQ4
IRQ3
DACK2
TC
ALE
+5 Volt
OSC
Ground
Ground
17
MSMX104 Manual V1.3
D:
Ground
MEMCS16
IOCS16
IRQ10
IRQ11
IRQ12
IRQ13
IRQ14
DACK0
DRQ0
DACK5
DRQ5
DACK6
DRQ6
DACK6
DRQ7
+5 Volt
MASTER
Ground
Ground
