DIGITAL-LOGIC AG
5
C
ONNECTORS ON THE
5.1 Connector for RS422/RS485 Interfaces
RS422/485 COM-A J18
J19 selected on J1-2
RS422/485 COM-B J16
J17 selected on 1-2
RS422/485 COM-C J14 Pin 1
J15 selected on 1-2
RS422/485 COM-D J12 Pin 1
J13 selected on 1-2
5.2 Connectors for RS232C interfaces
RS232C COM-A J4
J19 selected on 2-3
RS232C COM-B J5
J17 selected on 2-3
RS232C COM-C J6
J15 selected on 2-3
RS232C COM-A J7
J13 selected on 2-3
Pin 1
TX+
Pin 2
TX-
Pin 3
RX+
Pin 4
RX-
Pin 1
TX+
Pin 2
TX-
Pin 3
RX+
Pin 4
RX-
TX+
Pin 2
TX-
Pin 3
RX+
Pin 4
RX-
TX+
Pin 2
TX-
Pin 3
RX+
Pin 4
RX-
Pin 1
DCD
Pin 2
DSR
Pin 3
RxD
Pin 4
RTS
Pin 5
TxD
Pin 1
DCD
Pin 2
DSR
Pin 3
RxD
Pin 4
RTS
Pin 5
TxD
Pin 1
DCD
Pin 2
DSR
Pin 3
RxD
Pin 4
RTS
Pin 5
TxD
Pin 1
DCD
Pin 2
DSR
Pin 3
RxD
Pin 4
RTS
Pin 5
TxD
16
B
OARD
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
MSMX104 Manual V1.3
CTS
DTR
RI
GND
nc
CTS
DTR
RI
GND
nc
CTS
DTR
RI
GND
nc
CTS
DTR
RI
GND
nc
