Kobalt SGY-AIR214 Manual

Kobalt SGY-AIR214 Manual

1/4 in. ratchet wrench

Advertisement

Quick Links

®
KOBALT
and the K Design
trademarks of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-888-3KOBALT, 8:00 a.m.-8:00 p.m., EST,
Monday-Friday.
AB1404
®
are registered
RATCHET WRENCH
Purchase Date
1
ITEM #0498363
1/4 IN.
MODEL #SGY-AIR214
Français p. 16
Español p. 31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGY-AIR214 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kobalt SGY-AIR214

  • Page 1 ITEM #0498363 1/4 IN. RATCHET WRENCH MODEL #SGY-AIR214 Français p. 16 Español p. 31 ® ® KOBALT and the K Design are registered trademarks of LF, LLC. All Rights Reserved. ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT, 8:00 a.m.-8:00 p.m., EST,...
  • Page 2 TABLE OF CONTENTS Product Specifications ..................3 Safety Information .................... 3 Package Contents ................... 9 Preparation ....................... 9 Assembly Instructions ..................10 Operating Instructions ..................11 Care and Maintenance ..................13 Troubleshooting ....................Warranty ......................14 Exploded View....................15 Tool Requirements Exigences relatives aux outils Requisitos de herramientas IMPORTANT: To operate correctly, this tool requires airflow that is at least 5.1 cubic feet per minute (CFM) at 90 pounds per square inch (PSI).
  • Page 3: Product Specifications

    PRODUCT SPECIFICATIONS COMPONENT SPECIFICATIONS FREE SPEED 250 RPM SQUARE DRIVE 1/4 in MAXIMUM TORQUE 30 ft-lbs WORKING PRESSURE 90 PSI AVERAGE AIR CONSUMPTION 5.1 CFM AIR INLET 1/4 in. NPT RECOMMENDED AIR HOSE 3/8 in. (inside diameter) SAFETY INFORMATION Please read and understand this entire manual before attemptingto assemble, operate or install the product.
  • Page 4: Safety Information

    SAFETY INFORMATION WA R N I N G RISK OF EYE OR HEAD INJURY WHAT COULD HAPPEN HOW TO PREVENT IT This particular air powered tool can be Always wear ANSI approved Z87.1 safety capable of propelling materials such as glasses with side shields.
  • Page 5 SAFETY INFORMATION WA R N I N G RISK OF ENTANGLEMENT WHAT COULD HAPPEN HOW TO PREVENT IT Tools which contain moving elements or drive Do not wear loose clothing, jewelry, or anything other moving parts, such as impact sockets, that may get caught or tangled when using tool.
  • Page 6 SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT A tool left unattended or with the air hose Remove air hose when tool is not in use and attached can be activated by unauthorized store tool in secure location away from reach persons leading to their injury or injury to of children and untrained users.
  • Page 7 SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT Loss of control of the tool can lead to injury to Keep proper footing at all times. Do not self of others in the work area. overreach, as slipping, tripping, and or falling can be a major cause of serious injury and or death.
  • Page 8 SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT Follow lubrication instructions for best and There is a risk of bursting if the tool is safest operation. damaged. Follow assembly and repair instructions on how to properly change accessories.
  • Page 9 PACKAGE CONTENTS PART DESCRIPTION QUANTITY Ratchet Wrench Anvil Forward/Reverse Knob Trigger Air Inlet PREPARATION Before beginning the assembly of the product, make sure all parts are present. Compare parts with package contents list. If any part is missing or damaged, do not attempt to assemble the product.
  • Page 10: Assembly Instructions

    ASSEMBLY INSTRUCTIONS 1. Remove the air inlet protective cap from the air inlet (E) (See Figure 1). 2. Mount a male plug (not included) by hand into the air inlet (E) (See Figure 2). NOTE Use threaded sealant tape (not included) on the threading of the male plug.
  • Page 11: Assembly Instructions

    ASSEMBLY INSTRUCTIONS 4. Mount a 1/4 in. to 3/8 in. adapter (not provided) onto the anvil (B) if necessary, and then choose the correct impact socket (not provided) as needed and mount it onto the adapter (See Figure 4). WARNING Only use adapter and sockets that have a torque rating equal to or greater than the tool itself.
  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS Clockwise 2. To remove or loosen the threaded fasteners/workpiece, turn the forward/reverse knob (C) clockwise to the reverse position. Press the trigger (D). The tool anvil (B) runs counterclockwise removing/loosening the threaded fasteners/workpiece. Press...
  • Page 13: Care And Maintenance

    CARE AND MAINTENANCE Always remove tool from air supply before performing any maintenance on tool. An in-line oiler (not included) is recommended to be installed to air supply. It will help increase tool life and keep the tool properly lubricated. The in-line oiler should be regularly checked and filled with air tool oil as needed.
  • Page 14: Warranty

    WARRANTY This tool is warranted by the manufacturer to the original purchaser from the original purchase date for three (3) years subject to the warranty coverage described herein. This tool is warranted to the original user to be free from defect in material and workmanship.
  • Page 15: Exploded View

    Front Plate Spring Steel Ball Bearing Washer Washer Retainer Spring Thread Ring Gear Housing Idle Gear Gear Pin Gear Seat Clamp Nut Printed in China KOBALT and the K Design are registered ® ® trademarks of LF, LLC. All Rights Reserved.
