SET BUTTON
The SET button is used to manually step through the 5 stored output values.
1. Select the SOURCE mode
2. Press the SET button and the value stored in memory location 01 will be sourced. "MEM.01"
appears in the display.
3. Each press of the SET button will step through the 5 memory locations.
4. The arrow buttons can be used to adjust the value in each memory location.
STEP/MEM BUTTON
The STEP/MEM button is used to automatically step through the 5 stored output values. The meter
can be set for a single cycle of the stored values or a continuous cycle.
1. Select the SOURCE mode
2. Press and HOLD the STEP/MEM button. "STEPSS" (single cycle) and "STEPSC"
(continuous cycle) will alternately appear in the display. Release the button when the
desired mode is displayed.
3. In single cycle mode the meter will source the current or voltage displayed in MEM01 for 5
seconds. The meter will then advance to MEM02 for 5 seconds. This will continue through
MEM05 and then step down through the memory locations. The cycle will end when MEM01
has been reached.
4. In the continuous mode the cycle will continue until manually stopped.
5. Momentarily press the MEM button to stop the cycle. "END" will briefly appear in the display.
STORING VALUES INTO MEMORY
The default values stored in the memory locations are:
Memory
Location
M1
M2
M3
M3 y 8.00mA 25% 500mV5V
mA
4.00mA
8.00mA
12.00mA
emo 4.77-43.9 0 6
%
0.0%
25%
5
-1.651.(500mV)Tj(l2Tj2.055
mV V
0mV 0V
500mV 5V
