EXTREME ENVIRONMENTS. EXTREMELY RELIABLE.
Bubbler
User Manual
1.800.548.4264 | www.ftsinc.com
700-Bubbler-Man
Rev 2
14 Aug 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bubbler and is the answer not in the manual?

Questions and answers

Related Manuals for FTS Bubbler

Summary of Contents for FTS Bubbler

  • Page 1 EXTREME ENVIRONMENTS. EXTREMELY RELIABLE. Bubbler User Manual 1.800.548.4264 | www.ftsinc.com 700-Bubbler-Man Rev 2 14 Aug 2017...

  • Page 2: Contact Information

    Contact Information Canadian Headquarters: 1065 Henry Eng Place Victoria, BC | V9B 6B2 | Canada www.ftsinc.com Toll-free: 1.800.548.4264 Local: 250.478.5561 Technical support portal: http://support.ftsinc.com Email: service@ftsinc.com...
  • Page 3 CONNECTING AND INSTALLING THE ORIFICE LINE ....................6 2.6.1 Using the Swagelok® Fitting ..........................7 POWER CONNECTIONS ..............................8 CHAPTER 3 BUBBLER INTERFACE AND MENUS ............9 KEYPAD ....................................9 SCREENS, MENUS AND OPERATING THE USER INTERFACE ................9 3.2.1 Editing a Menu Item .............................10...
  • Page 4 5.2.2 X Commands List..............................27 APPENDIX A SPECIFICATIONS .................. 30 APPENDIX B TROUBLESHOOTING GUIDE ..............31 MECHANICAL INDICATORS ............................31 BUBBLER STATUS SCREEN FAULT INDICATORS ....................31 HEALTH STATUS/ERROR INDICATORS ........................32 B.3.1 MANAGING HEALTH STATUS INDICATORS ....................32 B.3.2 DETERMINING MULTIPLE HEALTH STATUS INDICATORS ..............33 APPENDIX C PARTS AND ORDERING INFORMATION ..........

  • Page 5: Chapter 1 General

    GENERAL INTRODUCTION The FTS Bubbler is an SDI-12 user configurable system for accurately measuring water stage in streams and reservoirs using pressure differentials. It is a self-contained, sealed system that includes an air compressor, control electronics and a high accuracy pressure sensor for measuring water levels. It can...

  • Page 6: Display And Keypad

    Bubbler or the data logger. This sets the Bubbler’s date and time which is used on the time stamp of the Bubbler’s SD card. It does not affect the time stamp of sent data or the timing of scheduled events as those are controlled by the data logger and the telemetry in use.

  • Page 7: Firmware Updates

    The Set Stage and Setup sub-menus on the Bubbler’s interface are used to configure the Bubbler. Refer to Chapter 3 for details. If the Bubbler is used with an FTS Axiom Datalogger, configuration is done through the Bubbler sensor extension. See Chapter 4 for details.

  • Page 8: Chapter 2 Installation

    The connectors and outlets should be pointing down. The bottom of the Bubbler should be free of obstruction so the orifice line has a free downward run. Ensure the orifice line is not bent or crimped.

  • Page 9: Sdi-12 Connections

    Ensure there are no kinks or bends in the output hose. Connect the output hose from the desiccator to the inlet fitting on the Bubbler. Secure both ends of the hose with a hose clamp. Follow the manufacturer’s directions with respect to handling, mounting, maintenance, and disposal of the desiccator and desiccant.

  • Page 10: Connecting And Installing The Orifice Line

     than the line outlet Once the orifice line run is securely laid out, connect the orifice line to the Bubbler outlet (refer to Figure 2-3) and secure it with the provided Swagelok® fitting. For a detailed explanation of the installation of an orifice line and static tube, refer to USGS publications: TWRI_8-A2: Craig, J.D, 1983, “Installation and service manual for U.

  • Page 11: Using The Swagelok® Fitting

    2) Screw the nut on until finger tight. 3) Mark the nut at the 6 o’clock position. 4) Hold the Bubbler outlet steady with a wrench, and use another wrench to tighten the nut one and a quarter turns (pass the 6 o’clock position once and stop at the 9 o’clock position).

  • Page 12: Power Connections

    Tighten the nut slightly. POWER CONNECTIONS The Bubbler requires a dedicated +12V power source to operate. This is normally supplied by an external lead-acid battery. Although the Datalogger supplies some power through the SDI port, it is only enough to view and operate the Bubbler’s screen. It is insufficient to run the compressor.

  • Page 13: Chapter 3 Bubbler Interface And Menus

    Chapter 3 BUBBLER INTERFACE AND MENUS The front panel has a display and keypad which is used to configure the Bubbler. When power is supplied, the start-up screen will display for about 5 seconds before the Status Screen is displayed.

  • Page 14: Editing A Menu Item

    Press the Select/Accept to save the changes. STATUS SCREEN The Bubbler’s status screen will display the site identification or any faults, the latest stage measurement, the calculated offset and the tank PSI. Note that if a custom slope was used to calculate the stage, the displayed unit of measurement will be “cu”...

  • Page 15: Bleeding The Tank

    If selected, the compressor will recharge the tank and operations will recommence. Once the tank is bled, the power connector to the Bubbler should be removed until maintenance is completed. Once maintenance is completed and power is re-established, operations will recommence.

  • Page 16: Configuring The Bubbler Using The Bubbler Interface

    Figure 3-4: Set Stage sub-menu Stage – Use the arrows to input the stage height. The Bubbler will use this value to calculate the offset which will be displayed on the Status Screen. Units – Use the up and down arrows to select the measurement units. The displayed Stage value will automatically be converted to the equivalent stage value in the newly entered measurement unit.

  • Page 17: Setup Menu

    2-60 seconds. SD Card: The SD card is used for service and factory logs and should only be accessed by trained FTS personnel. If no SD card is inserted the SDCARD option screen will display a dash. If an SD card is inserted the SDCARD option will display EJECT.

  • Page 18: Updating Firmware

    3.8.1 UPDATING FIRMWARE If there is a firmware update required, a notice shall be posted to the FTS Support Website with instructions on the firmware and how to download the update to a blank SD card. The only file on the SD card should be the firmware file.

  • Page 19: Chapter 4 Configuration Using Axiom Datalogger Interface

    The following screen will be displayed. Note that the Address displayed will be the address set in the Bubbler. In this example it is the default address of zero (0). Tap on the “New” field to bring you to the Bubbler Sensor Setup.

  • Page 20: Setup General Information

    SETUP GENERAL INFORMATION Each of the field names created in the Bubbler Sensor Setup tabs responds to a data point which will be displayed on the Bubbler’s summary screen. Once a data point is created it will be available for other functions such as Logging, Current Conditions, Processes, etc.

  • Page 21: Sensor Tab

    Offset Name: Input the desired name for the Stage Offset data point. The offset is calculated automatically by the Datalogger but will only be displayed on the main Bubbler Sensor screen if the Offset Name field is populated. See section 4.6.

  • Page 22: Mechanical Tab

    Line Pressure Name: The default name is LineP and can be changed if desired. Units are in PSI. Temperature Name: Insert the desired name for the temperature variable. Temperature Units: Select either C (Celsius) or F (Fahrenheit). 700-Bubbler-Man Rev 2 14 Aug 2017 Page 18/35...

  • Page 23: Purge Tab

    (every 24 hours) at 10:15 a.m. Purge if greater than To conduct purges when the line pressure exceeds a threshold value, select the Purge if greater than checkbox and input the desired threshold value. 700-Bubbler-Man Rev 2 14 Aug 2017 Page 19/35...

  • Page 24: Save Configuration

    BUBBLER SENSOR SCREEN From the home screen select the Sensors icon and then the Bubbler icon. Note that the name on the icon will be the same as the Sensor Name input on the Sensor tab. This example retains the default name.

  • Page 25: Conduct A Manual Purge

    If it is known use the Set Stage button. If it is not known, use the Polled feature. Staff Gauge Reading Known If the staff gauge reading is known, press Set Stage, enter the staff gauge value, and confirm the changes. 700-Bubbler-Man Rev 2 14 Aug 2017 Page 21/35...
  • Page 26 The polling option is meant as a temporary measure to confirm Bubbler operations and any data collected during the polling will not be recorded by the Datalogger. It will also not affect the Bubbler Setup values. That is to say, once polling is stopped, interval values will revert to those originally input in the Bubbler Setup Screen.
  • Page 27 STOP, scroll through the stage sensor readings and tap on the time that corresponds to your reading of the staff gauge. Press Select. 6. The Enter Staff Gauge Value screen appears. Enter the observed value and confirm. 700-Bubbler-Man Rev 2 14 Aug 2017 Page 23/35...
  • Page 28 7. Confirm the new Stage Settings 8. The new Stage Offset will be calculated. 9. De-select the Polled box. 700-Bubbler-Man Rev 2 14 Aug 2017 Page 24/35...

  • Page 29: Chapter 5 Sdi-12 Commands

    Chapter 5 SDI-12 COMMANDS STANDARD SDI-12 MEASUREMENT COMMANDS The Bubbler uses the standard SDI -12 Commands and protocols which makes it compatible for use with DCP’s or transmitters. The Bubbler’s specific measurement commands follow. Note the following: the “a” in each command should be replaced with the sensor address number ...

  • Page 30: Sdi -12 Measurement Command Codes

    1) M Command followed by the Get Data Command: 0M!00043 : Bubbler at address 0, measurements will be ready in 4 seconds, and 3 fields will be returned. 0D0!+5.23+0+0 :data returned is stage (5.23), units of stage code (feet) and health status code (0).

  • Page 31: Extended (X) Commands

    EXTENDED (X) COMMANDS In addition to the standard set of commands, the FTS Bubbler has an extension of custom SDI -12 commands called X commands that access specific features of the sensor. The format of X commands follows the requirement for standard SDI-12 commands in that the first character of every command must be a sensor address which is then followed by the X command and terminated by an exclamation mark.
  • Page 32 (gets Site ID of Bubbler1) aXIDP! Get/set site id aXIDbubbler1! (sets Site ID to bubbler 1) There is no error checking for symbols. If the user wants to enter symbols he can. But symbols are not supported from the display.
  • Page 33 You cannot use XSU to set the value to ‘5’ (you must use XSL If P = 6 temperature is Fahrenheit If P = 7 temperature is Celsius Get/set aXTUP! temperature units aXTU6!a aXTU!a6 700-Bubbler-Man Rev 2 14 Aug 2017 Page 29/35...

  • Page 34: Specifications

    (Depth) (0 to 21m) (0 to 70ft) Purge Pressure 20 to 90 PSI (user selectable) Gas Delivery Constant flow bubbler with user programmable bubble rate. 30 to 120 bubbles per minute AMBIENT CONDITIONS Operating Temperature -40°C to +60°C (-40°F to +140°F) Storage Temperature -60°C to +80°C (-76°F to +176°F)

  • Page 35: B.1 Mechanical Indicators

    Pump not running Insufficient power 1) Ensure Bubbler has a direct power source. It cannot be fully powered through the Datalogger’s SDI port (section 2.6.2). 2) Check power connections (including solar panel, if using)

  • Page 36: B.3 Health Status/Error Indicators

    Bubbler is still operating normally, but the bubbler’s SD card ’s time stamp will not be accurate. If your data logger can be programmed to set the Bubbler’s date and time every 24 hours (as the Axiom does), the appearance of this indicator can be mitigated.

  • Page 37: B.3.2 Determining Multiple Health Status Indicators

    3) 7 – 4 = 3 Health status value closest to 3 is 2 = the Bubbler has rebooted 4) 3-2 = 1 Health status Value closest to 1 is 1 = data logger and Bubbler are out of Synchronization...
  • Page 38 Appendix C PARTS AND ORDERING INFORMATION FTS Bubbler ordering information Part Number Description SDI-Bubbler Bubbler, SDI Spare Parts / Accessories Ordering Information Part Number Description 19861 Power Connector Assembly, Bubbler 19862 Data Connector Assembly, Bubbler 19865 Swagelok Nut Set, Bubbler 19443 1.5m SDI communication cable with flying leads both ends...

  • Page 39: Document Revision History

    DOCUMENT REVISION HISTORY Revision # Date Description SDI-12 commands based on ver 0.78 of the Bubbler SDI 1 Aug 2017 Command Set 14 Aug 2017 Updated for Axiom AS ver 3.8.0.57 (Bubbler extension) 700-Bubbler-Man Rev 2 14 Aug 2017 Page 35/35...
