- Page 1 G ateway Thermostat Model: ST910WZ Installation Guide...
- Page 2 Let’s Get Started Make sure you have the following items: Gateway Thermostat Terminal Block Wall Plate Decorative Cover Mounting Kit Installation Guide and wire labels...
- Page 3 Tools Required Small flathead Phillips Drill screwdriver screwdriver (for anchors) Optional Tools Digital Camera or Pencil Wire Stripper Smartphone...
- Page 4 Turn Off the Heating and/or Cooling Turn OFF the breaker(s) or remove the fuses to the heating and/or cooling systems at the electrical panel. In some regions, there may be a switch located near the furnace.
- Page 5 Expose Old Thermostat Wiring Unmount the old thermostat from the wall to expose the wiring and terminals. Take a picture of the terminals to record how the wires are connected.
- Page 6 Verify C Wire The Gateway Thermostat requires a C wire for power return. Verify that a wire runs to the C terminal of the old thermostat. If a C wire is not present, then a C-wire kit (model SA908-) needs to be installed.
- Page 7 Detach and Label Wires, and Clear Wall Note the terminals attached to each wire and attach the matching label to the ends of the wires. Wrapping the wires around a pencil can help prevent the wires from falling into the hole in the wall. When all wires have been disconnected, remove any other pieces of the old thermostat that may still be attached to the wall.
- Page 8 Decide on Orientation The Gateway Thermostat can be mounted in either a horizontal or vertical orientation to best fit the décor. Horizontal Orientation Vertical Orientation The following instructions will use the above pictures as icons should any instruction be orientation dependent.
- Page 9 Mount with Decorative Cover If the wall behind the Gateway Thermostat needs to be covered, the Wall Plate and Decorative Cover can be used by inserting them between the Terminal Block and the wall. or...
- Page 10 Install Terminal Block There are three possible situations when mounting the Terminal Block. Follow the instructions for your specific situation. A. Mount to a junction B. Mount C. Mount to a box box in the desired directly on NOT in the desired orientation the wall orientation...
- Page 11 A) Desired Orientation Junction Box There are 2 steps to mounting on a junction box in the same orientation as the desired orientation. 1. Align Terminal Block holes to junction box holes. 2. Use junction box screws to attach Terminal Block to box. Insert the Wall Plate and Decorative Cover if desired.
- Page 12 B) Mount Directly on the Wall There are 4 steps to mounting directly on the wall. 1. Mark hole locations (83mm or 3-9/32” apart) 2. Drill holes for anchors (3/16” bit)
- Page 13 3. Insert anchors or 4. Attach Terminal Block by screwing into anchors or...
- Page 14 C) Different Orientation Junction Box There are 3 steps to mounting on a junction box not oriented in the desired direction. This situation uses the Wall Plate to change the orientation of the junction box mounting holes. 1. Orient the Wall Plate in the desired thermostat direction and use junction box screws to attach the Wall Plate to the mounting holes of the junction box.
- Page 15 2. Snap the Decorative Cover over the Wall Plate. 3. Attach Terminal Block to Wall Plate using quarter turn pins.
- Page 16 Attach Wiring Before attaching the wires, match the label on the wires to its corresponding terminal. Refer to the picture of the wiring taken earlier if necessary. Attach the wires by pressing on the latch next to the terminal, inserting the wire into the side hole and releasing the latch. Pull on the wire after releasing the latch to verify that the wire is firmly secured. Push any excess wire into the wall or junction box.
- Page 17 Attach Thermostat to Terminal Block Once all the wires have been attached, including the C wire, snap the thermostat onto the Terminal Block, making sure the terminal connector is aligned.
- Page 18 Turn the Power Back On to the HVAC System Go to the electrical service panel or furnace switch and turn the HVAC system back on.
- Page 19 Configure the Thermostat The Gateway Thermostat can now be configured for the HVAC system and connected to the Salus Smart Home service. The onscreen instructions will guide you through the configuration and pairing process.
- Page 20 During the warranty period, Salus shall, at its option, repair or replace any defective Products, at no charge for the device. Any replacement and/or repaired devices are warranted for the remainder of the original Warranty Period or ninety (90) days, whichever is longer.
- Page 21 No oral or written information or advice given by Salus or a Salus- authorized representative shall modify or extend this warranty. If any term is held to be illegal or unenforceable, the legality or enforceability of the remaining terms shall not be affected or impaired.
- Page 22 FCC Statements WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 23 FCC and Industry Canada RF Radiation Exposure statement: This equipment complies with FCC and Industry Canada RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the antenna and all persons. Cet appareil est conforme aux limites d’exposition au rayonnement FR du FCC et d’Industrie Canada pour un environnement non contrôlé.
- Page 24 SALUS North America, Inc. 850 Main Street Redwood City, CA 94063 Version 1...
