2.

Installation

2.1

Transport instructions

The machine comes to you in a box or shrink-wrapped. If you have to
transport the machine at any time it is recommended that you use a
similar box and packing methods. Please let the machine cool down
and move the handle to the locked position, with a mug clamped in
printing position.
2.2

Installing the machine

2.2.1 Remove all packaging from the heat press.
2.2.2 Check to ensure that no damage has been caused to the
machine during transit.
2.2.3 Place the machine on a sturdy horizontal surface that is within
easy reach of the operator and allow space for the handle to
move to the loading position. Ensure that no items vulnerable
to heat radiation are too close to the machine.
2.3

Electrical requirements

The Studio Mug Press should be connected to the mains supply,
(nominally 230V AC for the European Market), by the mains cable
provided and a suitable plug.
The press is designed for 230Volts AC 50/60 hertz and requires
exclusive use of a power outlet rated for at least 3.15Amps (Europe), or
for 110Volts AC 50/60 Hertz rated for at least 3.15Amps (America).
Ensure that the supply rating on the machine specification plate
corresponds with your local supply and that the correct plug is fitted.
Wiring the plug for a 230V AC Machine.
The wires in this mains lead are coloured in accordance with the
following code:
Green and Yellow:
Blue:
Brown:
As the colours of the wires in the mains lead of this apparatus may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:-
EARTH
NEUTRAL
LIVE
