- Page 1 Model • PH Ultraslim THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. BE SURE TO OBSERVE ALL LABELS AND WARNINGS ON THE APPLIANCE Id.-Nr. 900 370 411 Edition :01/18 Feel good through warmth from electricity - www.technotherm.de...
-
Page 2: Very Important
7.Pictogram for program creation, status in normal mode. 8.Display zone for Time, Temperatures and parameters. 9.Override function in AUTO mode or ITCS function activated if blinking. 10.Room temperature indicator. 11.Pictogram for open widows indication 12.Heating demand. Feel good through warmth from electricity - www.technotherm.de... -
Page 3: First Installation
Use the navigation key right (>) to display the working mode line. Move the frame cursor on the desired working mode and press (OK) to enter in the operating mode you have chosen. Feel good through warmth from electricity - www.technotherm.de... - Page 4 When you enter in the Program mode, the first operation is to choose the program number using the (-) or (+) keys you can choose between a built-in program P1 to P9 or a user program U1 to U4. Select a program and press (OK) to validate. Programm number Feel good through warmth from electricity - www.technotherm.de...
- Page 5 • The program creation will always start with day 1 (Monday). • The (>) Button switches between the ECO temperature and the COMFORT temperature mode in the time displayed on the screen. Feel good through warmth from electricity - www.technotherm.de...
-
Page 6: Special Functions
Now you can select the parameters which must be adjusted with the navigation keys ( ). Press the (OK) key to edit the parameter that you wish to modify and change its value with (+) or (-), then confirm with (OK). Feel good through warmth from electricity - www.technotherm.de... - Page 7 Default: 900 W Clr: Factory setting Press and maintain (Ok) key during 10s to reset Set points temperatures and user parameters in this menu to factory default settings. User programs will also be resetted. Feel good through warmth from electricity - www.technotherm.de...
-
Page 8: Technical Characteristic
My Thermostat seems work correctly but the temperature in the room was never in accordance with the program. Program - Check the Clock. -The difference between Comfort & Reduced temperature is too high? - The step in the program is too short? - Check the pilot wire function. Feel good through warmth from electricity - www.technotherm.de... -
Page 9: Installation
4. Screw the brackets to hold the radiator into place, usingthe screws and washers provided. 5. Hang the radiator using the brackets. 6. Mark the position of the hooks drill and plug holes andscrew in place. Feel good through warmth from electricity - www.technotherm.de... - Page 10 8. Place the radiator brackets in place using the supplied screws, stoppers and washers. 9. Approach the radiator to the brackets so that the grooves match with the ones on the bracket. 10. Hang the radiator and secure it with the screws. Feel good through warmth from electricity - www.technotherm.de...
- Page 11 • This heater is for domestic & light commercial use only, installation in any other environment voids thisguarantee • Technotherm reserves the right to decide whether to repair or replace any defective part or to replace the entire heater. • All costs arising from any damage caused by incorrect usage, transport, electrical supply are not coveredby this guarantee, nor is any malicious damage.
- Page 12 Contact Information: Lucht LHZ Elektroheizung GmbG & Co. KG | Reinhard-Schmidt.Str.1 D-09217 Burgstädt TECHNOTHERM Support TECHNOTHERM a brand of Lucht LHZ GmbH & Co. KG Reinhard-Schmidt-Str. 1 | 09217 Burgstädt | Germany +49 (0) 911 937 83 210 Telefon: +49 (0) 3724 66869 0 Telefax: +49 (0) 3724 66869 20 info@technotherm.de | www.technotherm.de...
