Installation and technical manual
VPS-Design Wall mounting
VPS-Design B 1000 – 2000 RF
VPS-Design W 1000 – 2000 RF
VPS-Design M 1000 – 2000 RF
VPS-Design B/W/M 1200 H RF
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE
REFERENCE. BE SURE TO OBSERVE ALL LABELS AND WARNINGS ON THE APPLIANCE
Edition: 01/18
Id_Nr.911 361 911
D
GB
Advertisement
Related Manuals for Technotherm VPS-Design B 1000
Summary of Contents for Technotherm VPS-Design B 1000
- Page 1 Installation and technical manual VPS-Design Wall mounting VPS-Design B 1000 – 2000 RF VPS-Design W 1000 – 2000 RF VPS-Design M 1000 – 2000 RF VPS-Design B/W/M 1200 H RF THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE.
- Page 2 Manual VPS-Design 1. For your safety • This appliance is intended for normal household use and not for use for vehicles or on board ships or aircrafts. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction...
- Page 3 Manual VPS-Design • CAUTION — Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present. • Make sure that your supply rating corresponds to what specified on the rating plate: 230V~, 50Hz.
- Page 4 Manual VPS-Design Warning! this device has to be grounded This device may only be operated using alternating current and the operating voltage indicated on the power rating plate • Nominal Voltage 230V AC, 50 Hz • Protection Class • Degree of Protection IP 24 •...
-
Page 5: Maintenance
Manual VPS-Design 3.1.4 Receiver RF- Technical Specifications • Power Supply 230 V, 50 Hz +/-10% Protection Class II • Expenditure : 0,5 VA • • Switching capacity max.: 16 A 230 Veff Cos j =1 or max. 300 W with lighting control Radio Frequency 868 MHz (NormEN 300 220), •... - Page 6 Manual VPS-Design 5.1 Wall Installation When installing the device, the safety distance must be strictly adhered to, so that flammable materials can not ignite. Install the device to a wall which is heat resistant up to 90 ° C. • Due to possible fire hazard the safety distances are observed during assembly: Side walls of the heater to any masonry: 5 cm Side walls of the heater to combustible materials:...
- Page 7 Manual VPS-Design 5.3 Mounting to the wall Model Power With High Deep [mm] [mm] [mm] [mm] [mm} [mm] Weight [Watt] [kg] VPS RF 1000 1000 VPS RF 1200 1200 1500 1050 RF1500 VPS RF 2000 1050 2000 VPS H 1200 1200 1054 Edition: 01/18...
- Page 8 Manual VPS-Design Additional mounting information Drill three holes of 7mm and fix the wall bracket. Screw in the three 4 x 25 mm screws into the wall Click the heater first at the top into the wall bracket and then at the bottom. The heater will be fixed “automatically”.
- Page 9 • RF Receiver together with the TPF-Eco Thermostat (Art.Nr.: 750 000 641) and the Eco- Interface (Art.Nr.750 000 640) from Technotherm meet the following requirements and therefore the ErP Directive: electronic room temperature control plus week timer • Installation of the receiver and the interfaces see separate instructions. For customer service - see last page.
- Page 10 Lucht LHZ Elektroheizung GmbG & Co. KG | Reinhard-Schmidt.Str.1 D-09217 Burgstädt Lucht LHZ Elektroheizung GmbH & Co. KG Reinhard-Schmidt-Str. 1 D 09217 Burgstädt Fon: +49 (0) 3724 66869 0 Fax: +49 (0) 3724 66869 20 E-mail: info@technotherm.de web: www.technotherm.de Edition: 01/18...
